Non-Contact Angle Sensors feature redundant outputs.

Novotechnik U.S., Inc.    Southborough, MA 01772
Mar 27, 2013 Offering factory programmable measurement angles from 45–360°, RSC3200 Series delivers output of 0.25–4.75 or 0.5–4.5 V, depending on customer preference, with 12-bit resolution and repeatability of ±0.5°. Hall-effect angle sensors operate from -40 to +125°C and have IP 69K rating for protection against dust and humidity. With temperature resistant housing and standard D-shaft connector interface, sensors are suited for automotive and off-highway vehicle applications.

Non-Contact Rotary Position Sensor consumes 300 µA at 3.3 V.

Novotechnik U.S., Inc.    Southborough, MA 01772
Feb 13, 2013 Operating from 1.8–5.5 V supply, Contelec Vert-X 21 LP Series can be ordered as 3-wire angle sensor or programmable version with up to 2 switch outputs, custom measurement angle, start- and end-point settings, custom characteristic curve and/or sense of rotation. Products offer 0° to 360° measurement range, 12-bit resolution, repeatability to 0.1°, and max hysteresis of 0.2° Measuring less than 1 in. dia, IP65-rated sensors have life rating of 360+ million movements.

Programming System supports rotary angle sensors.

Novotechnik U.S., Inc.    Southborough, MA 01772
Nov 21, 2012 Available for Vert-X MH-C2 line of programmable rotary angle sensors and encoders, EasyAdapt Programming Tool consists of programming software, hardware programming device, and cables to connect device to user's PC and sensor being programmed. System lets users program output characteristics including custom characteristic curve, angle range, zero point, and direction of rotation. Users can select from 6 default set-ups or use one as starting point and customize it.

Rotary Position Sensors have measurement range of 0-360°.

Novotechnik U.S., Inc.    Southborough, MA 01772
Nov 07, 2012 Measuring position at distances up to 25 mm, RFC4800 Series rotary angle sensors include 2 PNP positive switched outputs and programmable switching zone. Edge width of switch function is less than or equal to 0.1°, while accuracy of switch edges is ±1°. Sensors have magnetic pickup enabling touchless measurement, IP67-sealed 4-20 mA current output, 12-bit resolution, and ±0.5% independent linearity. Units operate over temperature range of –40 to +85°C and withstand shock up to 100 G.

Linear Position Sensors feature programmable end-points.

Novotechnik U.S., Inc.    Southborough, MA 01772
Oct 02, 2012 Based on Novopad non-contacting inductive technology, LS1 Series is insensitive to magnetic fields and has no mechanical sensor track. Units offer measurement range of 25–100 mm for return spring version and 25–200 mm for rod only version, with resolution to 0.05% and repeatability to less than 0.05%. Output range can be programmed either the same as, or independent of, actual travel length by setting Min and Max output levels. Output options include: 0.1–10 V, 4–20 mA, 10–0.1 V and 20–4 mA.

Magnetostrictive Position Sensors eliminate adjustments.

Novotechnik U.S., Inc.    Southborough, MA 01772
Jun 08, 2012 Providing non-contact, absolute, linear position, TP1 Series meets all specifications without null and span adjustments. Units come in standard measurement ranges of 50-4,500 mm with update rate of 62 µsec, absolute linearity to within ±0.02% of FS, and 16-bit resolution. Output versions include analog, start/stop, SSI, Quadrature, and 48-bit DyMoS that also provides true velocity without need of encoder. Sealed to meet IP68 standard, sensors operate from -40 to +85°C.

Touchless Rotary Angle Sensors suit off-highway vehicles.

Novotechnik U.S., Inc.    Southborough, MA 01772
Nov 25, 2011 Measuring 3.54 in. diam x 0.59 in. height, Vert-X 90E Series features 0-360°measurement range and 0.1° repeatability. Magnetic pick up is secured to rotating object so there is no direct mechanical linkage between shaft and measuring system and no wear. Available with IP68 or IP69 protection rating, sensors offer up to 2 switch outputs, independent linearity to 0.3%, and 14-bit resolution. Output options include voltage of 10-90% of power supply, SPI, and PWM.

Rotary Position Sensors support application-specific tailoring.

Novotechnik U.S., Inc.    Southborough, MA 01772
Jul 28, 2011 Comprised of 0.866 in. dia touchless rotary sensors, programmable Vert-X 22E Series uses magnetic pick up secured to rotating object. Lack of any direct mechanical linkage between shaft and measuring system eliminates wear. Offered in 5 and 24 V supply versions, sensors have 0° to 360° measurement range, up to 2 switch outputs, and 14-bit max resolution. Repeatability and hysteresis are less than or equal to 0.1°, and output options include voltage of 10%-90% of power supply, SPI, and PWM.

Touchless Rotary Position Sensor delivers wear-free operation.

Novotechnik U.S., Inc.    Southborough, MA 01772
May 12, 2011 Without any direct mechanical linkage between shaft and measuring system, Vert-X 22 Series employs permanent magnet secured to rotating object. These touchless, magnetic angle sensors have 0° to 360° measurement range and up to 14-bit resolution. With 8 output options, IP68-rated absolute sensors measure less than 1 in. dia and feature repeatability of 0.1° or better and max hysteresis of 0.1°. Redundant output versions are also available.

Multi-Turn Rotary Sensors use magneto-resistive technology.

Novotechnik U.S., Inc.    Southborough, MA 01772
Mar 11, 2011 RSM 2800 Series supplies absolute position values and rotational counts up to 16 turns without mechanical gearing, batteries, or optics. Non-contact sensors permanently store shaft rotation as well as position when power is lost. When power is restored, units automatically provide accurate position and count. Measuring 30 mm in dia with 6 mm dia shaft, sensors offer independent linearity up to ±0.25%, electrical range up to 5,400°, and repeatability of ±1 LSB.

Non-Contact Linear Position Sensor mounts in cylinder.

Novotechnik U.S., Inc.    Southborough, MA 01772
Nov 15, 2010 Comprised of rod-style sensors intended for integration within hydraulic and pneumatic cylinders, TIM Series comes in nominal stroke lengths from 50-2,500 mm and operates under pressure to 350 bar with peaks to 530 bar. Magnetic pick-up position marker is mounted on application's piston rod. Shock and vibration ratings are 100 g and 25 g, respectively, and independent linearity is less than or equal to 0.04% FS. Other characteristics include ±0.01% FS repeatability and 5 µm resolution.

Linear Position Sensors offer stroke lengths up to 300 mm.

Novotechnik U.S., Inc.    Southborough, MA 01772
May 20, 2010 Featuring 18 mm diameter housing that is sealed to IP67, TX2 Series offers linearity to 0.05% with resolution better than 0.01 mm. Pivot heads provide large angle of free movement up to ±12.5°. Available from stock with 8 stroke lengths from 25-300 mm, sensors operate for more than 50 million movements and withstand adverse environmental conditions such as humidity and dust.

Signal Conditioner is designed for position measurement.

Novotechnik U.S., Inc.    Southborough, MA 01772
Aug 11, 2009 Computer-controlled MUP400 features 16-bit resolution and accuracy of ±0.01 of range +1 digit. It converts potentiometric input signals into standard voltage or current signals, with sample rate of up to 5 kHz, and allows span to be limited to 80% of total input range. At 90.5 x 79 x 25 mm, unit is designed for DIN EN 50022 mounting rail fixture. It features temperature range is 0-60°C, with drift of 25 ppm/K, and operates from 18 to 30 Vdc supply.

Rotary Position Sensors suit industrial/vehicle applications.

Novotechnik U.S., Inc.    Southborough, MA 01772
May 08, 2009 Designed for harsh environments, SP 5000 Series sensors convert rotary movement into proportional voltage. Housing and bearings are manufactured with high-grade temperature-resistant plastic and units include 3-pin AMP Junior-Timer connector and metal multifinger wiper for contact. Targeting automotive applications with 105 and 120° electrical angle measurements, units offer repeatability of 1.0°, tolerate vibrations to 20 G, and operate in temperatures from -40 to +125°C.

Multi-Turn Rotary Sensors employ non-contact technology.

Novotechnik U.S., Inc.    Southborough, MA 01772
Apr 28, 2009 Able to sense without contact or power, RSM 2800 Series combined multi-turn rotation counter and position sensor series is based on novoturn(TM) technology and built on magnetic resistance effect. There are 2 multi-turn elements offset by 90º in diamond pattern, and second 360° sensor used to determine specific angle in single-turn range. Series can measure angles between 2 and 15 turns and supply absolute position values over 360° without mechanical gearing or buffer.

Process Monitor/Controller performs 40 measurements/sec.

Novotechnik U.S., Inc.    Southborough, MA 01772
Nov 18, 2008 Operated by 5 buttons on front panel or remotely via serial interface, MAP 4000 Series includes programmable input selection and mathematical functions as well as up to 4 limit switches. Multifunctional inputs are programmable for potentiometers, DC voltage, current/voltage, resistance, and temperature sensors. Providing isolated RS 232 or RS 485 outputs, MAP 4000 Series offers measurement range of -99,999 to 999,999 with accuracy of 0.1% +1 digit of full scale.

Rotary Touchless Sensor suits transmissive measurements.

Novotechnik U.S., Inc.    Southborough, MA 01772
Oct 02, 2008 Built with 1 in.² thumbprint and 7 mm profile, RFC 4000 Series combines sensor and magnetic position marker to offer unlimited mechanical life. Touchless technology utilizes orientation of magnetic field in order to determine measurement angle, and analog output signal used to represent calculated angle is repeatable to ±1 LSB. Unaffected by dust, dirt, and moisture, unit has programmable electrical range to 360°, 12-bit resolution, and independent linearity to less than ±0.3%.

Rotary Position Sensors utilize touchless technology.

Novotechnik U.S., Inc.    Southborough, MA 01772
Dec 06, 2007 Suited for mobile and harsh environments, RSC Series features non-contact technology with rotating shaft, while Vert-x E Series has no shaft, but includes round position marker that mounts separately from detecting sensor component. Sensors offer programmable angular range to 360° and resolution to 14 bits. They range from miniature units measuring 13 mm dia for use in tight applications to rugged 48 mm rotary angle models sealed up to IP69K for adverse conditions.

Rotary Sensor offers less than ±0.5% independent linearity.

Novotechnik U.S., Inc.    Southborough, MA 01772
Jul 12, 2007 With operating temperature range of -40 to 85°C, Series RSC 2800 non-contacting rotary position sensors are designed to operate in extreme industrial environments and provide protection to IP 65 standard. Performance is unaffected by static/dynamic shaft loads of up to 20 N in both radial and axial directions. Features include electrical measurement angle of 30-360°, lifespan of more than 50 mil movements, and repeatability of less than 0.03% of output signal range.

Compact Position Sensors feature pressure equalization.

Novotechnik U.S., Inc.    Southborough, MA 01772
Jul 31, 2006 Offered in 18 mm dia housing with stroke lengths up to 300 mm, TEX series uses differential pressure compensation technology to equalize pressure that builds up from rod movement on linear sensors. IP66-rated series withstands adverse environmental conditions such as humidity, oil, and dust while exhibiting ±0.05% linearity and better than 0.01 mm resolution. Pivot heads eliminate side-load errors, and series has operating life rated for up to 20 million movements.
