Boundary-Scan Controller offers sustained clock speeds of 40 MHz.

Jtag Technologies Inc    Stevensville, MD 21666
Aug 24, 2012 Supporting PXIe/Compact PCI-express slot format, DataBlaster JT 37x7/PXIe satisfies requirements for high-speed In-System Programming of flash memories, serial memories, and CPLDs as well as complex digital circuit testing. Controller uses Enhanced Throughput Technology and features on-board flash image buffer memory. Supplied with complementary QuadPOD(TM) system, DataBlaster/PXIe offers 4 synchronized Test Access Ports able to support multi-TAP test targets or gang programming of 4 TAP targets.

Multifunction JTAG I/O Module tests digital and analog PCBs.

Jtag Technologies Inc    Stevensville, MD 21666
Jul 05, 2012 Using QuadPod signal conditioning interface for PCB access, JT 2149/DAF mixed-signal measurement module has 16 pins capable of digital I/O stimulus and response at voltages of 1.0-3.6 V, plus frequency measurements of up to 128 MHz. Unit's 12 analog measurement channels capture values from 0-33 V, with better than 10 mV resolution. Additional clock generator channel is programmable up to 64 MHz. Module is controlled via ProVision software and through Python(TM) scripts.

JTAG/Boundary-Scan Tool facilitates debug, repair operations.

Jtag Technologies Inc    Stevensville, MD 21666
Oct 04, 2011 AutoBuzz uses seek and discover feature to completely scan compliant design and then perform comparative tests using JTAG/boundary-scan. Users, with JTAG scan-chain information plus BSDL models of JTAG/IEEE std 1149.1 compliant parts, can connect to designs via number of compatible JTAG interface options. Program can then be set to gather complete connectivity map of any board's boundary-scan to boundary-scan pin connections.

JTAG/Boundary-Scan Interface targets functional testers.

Jtag Technologies Inc    Stevensville, MD 21666
Sep 19, 2011 Based on QuadPod architecture and designed in MAC Panel Direct Access Kit (DAK) form factor, JT 2147/DAK signal conditioning module enables seamless connections from PXI DataBlaster to MAC-Panel Scout mass interconnect system. Functionality lets test system builders simplify wiring tasks while retaining optimal signal integrity. System features 4 independent JTAG Test Access Ports (TAPs), each programmable to operate through various voltage levels, and 16 user-assigned DIO channels.

USB Controller offers max programmable TCK speed of 6 MHz.

Jtag Technologies Inc    Stevensville, MD 21666
Oct 27, 2010 Consisting of single tap, IEEE Std. 1149.1 boundary-scan controller, JTAGLive includes built-in support options for Altera and Xilinix hardware. PC-powered unit features single test access port and programmable output voltages and input thresholds. Controller is designed for use exclusively with JTAGLive suite of software tools that include Buzz continuity tester, Clip interactive cluster test generator, and Script Python-based boundary-scan scripting system.

Software/Hardware System supports boundary scan test routines.

Jtag Technologies Inc    Stevensville, MD 21666
Oct 14, 2010 Suited for board-level and system designers, ProVision Designer Station provides automatic test program generation for interconnections and in-system programming for devices. Scripting library known as JFT leverages open-source Python(TM) language to add sophisticated test options for logic clusters and for programming of memory devices. Additional interactive tools, such as ActiveTest, enable rapid generation of simple cluster tests and checks that might require small number of test patterns.

Boundary Scan Software creates hardware test programs.

Jtag Technologies Inc    Stevensville, MD 21666
Jun 15, 2010 JTAG ProVisionT v1.8 offers continuity test module for checking hidden open circuits. It features pin-level ActiveTest interactive cluster test generator as well as NAND flash ISP program generator. Test debug for Symphony-supported in-circuit testers is included along with flying-probe tester and multiboard and scan bridge support for JFT(Python) script routines. Software also integrates ProVision model library with models for more than 7,500 non-boundary-scan devices.

Boundary-Scan Controller supports PCIe slot format.

Jtag Technologies Inc    Stevensville, MD 21666
Nov 20, 2009 DataBlaster JT 37x7/PCIe offers sustained test clock speeds of up to 40 MHz and uses Enhanced Throughput Technology(TM) to support memories with data-bus widths from 1 bit to 64 Kbit. Unit includes 4 synchronized test access ports (TAP) that support multiTAP test targets or gang programming of 4 TAP targets. It features QuadPOD(TM) with high-speed signal conditioning, logic threshold adjustments, and cable delay compensations. Flash image buffer memory is expandable to 128 Mbits.
