Open Frame Monitor features 24 in. LED-backlit panel.

Caltron Industries, Inc.    Fremont, CA 94538
May 14, 2013 Offered as replacement for FWT-2407O, LWT-2407O incorporates 24 in., LED-backlit, 250 nit TFT LCD panel that can produce 16 million colors for digital signage applications as well as industrial applications. Widescreen solution can be used as open frame or touchscreen monitor and offers 1920 x 1080 WXGA max resolution, 5000:1 typ contrast ratio, and 12 msec typ response time. Viewing angles – left/right and up/down – are ±89°.

Ultra Wide Bar LCD Monitor delivers dynamic content.

Caltron Industries, Inc.    Fremont, CA 94538
Apr 05, 2013 Supplied with all necessary cables, 28 in. SD-281 Ultra Wide Stretched Bar LCD Monitor is suitable for docking platforms of rapid transit or airport terminals to display advertisements or general information. Monitor supports MP-1080N HD digital signage player with zoning capabilities, enabling images and videos to be configured to fit into screen. Ultra wide stretch display can be integrated into almost any application and is also suitable for restaurants and bars.

Digital Signage Player can loop HD content 24/7.

Caltron Industries, Inc.    Fremont, CA 94538
Feb 07, 2013 Capable of looping content 24/7, stand-alone MP-1080B can use SD card that holds up to 32 GB of content for providing HD quality videos and images. Content can be played in 1,920 x 1,080 resolution (1080p), and player also supports H.264 files in addition to other file formats. Industrial-grade unit endures harsh environments without failing, and physical dimensions allow it to be hidden away from any area visible to visitors.

LED Backlit Monitor features open frame design.

Caltron Industries, Inc.    Fremont, CA 94538
Dec 21, 2012 Rated at 1,000 nits or cd/m², 8.4 in. HBT-0842O High Bright Monitor is suited for photo booths, outdoor ticketing machines, kiosks, and instrumentation controls. Unit offers option of adding on additional ports to satisfy project needs and can also have touch application integrated, such as resistive or surface acoustic wave touch panel. Monitor is especially useful for signage applications that are located outdoors or in areas with bright lights.

High Brightness Open Frame Monitor can be read in sunlight.

Caltron Industries, Inc.    Fremont, CA 94538
Nov 13, 2012 Featuring 1,500 nit LED panel, HBT-1704O offers 1,280 x 1,024 (SXGA) max resolution, 1,000:1 typ contrast ratio, 80% min uniformity, and 5 msec response time. This 17 in. open frame monitor, with backlight MTBF of 50,000 hr minimum at 25°C, can display 16 million colors and offers viewing angles of ±85° left/right, +80° up, and -80° down (typ at CR=10). Also available with touch options, product is suited for direct sunlight and industrial applications.

LED Monitor delivers brightness rating of 1,400 nits.

Caltron Industries, Inc.    Fremont, CA 94538
Aug 21, 2012 Featuring sunlight readable screen, 19 in. Model HBT-1904O is suitable for indoor and outdoor environments. Open frame unit offers both resistive and surface acoustic wave touch options. With proper shading and design, integrators can use high bright monitor to optimize digital signage applications.

Industrial Touch Monitors feature front sealed designs.

Caltron Industries, Inc.    Fremont, CA 94538
Jul 18, 2012 Constructed for protection against harsh environments that may have high volumes of dust or liquid in proximity to unit or enclosure, 19 in. IPR-1904O resistive touch LCD and 19 in. IPS-1904O SAW touch LCD are UL compliant and front sealed. These industrial touch monitors, accommodating any application that requires monitor with bezel, are designed to facilitate integration into any application and feature standard VESA mount in back.

Open Frame LED Monitor features 350 nit brightness rating.

Caltron Industries, Inc.    Fremont, CA 94538
Dec 07, 2011 Suited for integration into enclosure, 19 in. Model LBT-1904O features 376.32 x 301.06 mm active area, 1,280 x 1,024 max resolution, 16 million display colors, and contrast ratio of 1,000:1. Monitor operates from 32-122°F and includes standard 15-pin VGA input connector. Suited for instrumentation panel displays, kiosks, and photo booths, monitor is available with resistive or surface acoustic wave touch option as well as serial or USB touch interface.

Open Frame LED Monitor features high bright design.

Caltron Industries, Inc.    Fremont, CA 94538
Nov 14, 2011 Rated at 1,500 nits, 15 in. Model HBT-1503O is suitable for indoor and outdoor use. Monitor comes with resistive or surface acoustic wave touch option and serial or USB touch interface. Available with DVI input, Composite Video input, or BNC input, monitor is intended for integrators, OEMs, and end user applications.

Open Frame LED Monitor is designed for industrial applications.

Caltron Industries, Inc.    Fremont, CA 94538
Oct 03, 2011 Available in standard open frame or touchscreen version, 6.5 in. LBT-0651O delivers 800 nits of brightness for visibility in indoor/outdoor environments. TFT LCD Panel, along with 132.48 x 99.36 mm active area, features 4:3 aspect ratio, 640 x 480 resolution, 600:1 typ contrast ratio, and 25 ms response time. For connectivity, 15-pin VGA input connector comes standard while DVI, composite, and BNC video input options are also available. Viewing angles are ±80°L/R and ±70°U/D.
