Semi-Automatic MIG Gun withstands heavy-duty use.

Bernard Welding Equipment    Beecher, IL 60401
May 06, 2013 Straight-handle T-Gun™ Semi-Automatic Air-Cooled MIG Gun models are rated at 350, 450, 550, and 650 A, while Compact Series features 350 A model. Product includes Double-Life MIG Gun System, so users can replace front end of gun with identical back end. Also included are aircraft-grade aluminum armored neck with insulated copper conductor tube, rated over 650 A, and heat-dissipating consumables. Unit is available with power cables in 10, 12, 15, 20, 25 ft, and custom lengths.

MIG Gun eliminates downtime associated with neck replacement.

Bernard Welding Equipment    Beecher, IL 60401
Feb 13, 2013 With its locked, rotatable neck, Bernard® S-Gun™ 250 amp MIG Gun helps eliminate downtime associated with missing MIG gun necks. Ergonomic handle is constructed of high-impact, glass-reinforced composite, and steel monocoil power cable is designed with lightweight steel coils that offer conduit for shielding gas flow and wire feeding. Gun is compatible with Weld Cable Control (WCC) Systems from Miller Electric Mfg. Co. as well as Quik Tip™ Series Consumables.

Fume Extraction Gun is designed for operator comfort, control.

Bernard Welding Equipment    Beecher, IL 60401
Jun 11, 2012 Available in 300 and 400 A configurations with 50° neck bend, FILTAIR® Fume Extraction Gun complements FILTAIR Systems from Miller Electric Mfg. Co. and is suited for solid wire welding applications. Vacuum regulator at front of handle allows for balance of suction with shielding gas flow, and vacuum chamber size promotes joint access and visibility. Vacuum hose swivel at rear of handle lends to operator comfort and control, and chrome-plated front end resists spatter adhesion.

Flux-Cored Welding Gun features replaceable power cable liner.

Bernard Welding Equipment    Beecher, IL 60401
Mar 27, 2012 Providing 350 A at 60% duty cycle, Dura-Flux(TM) Self-Shielded Arc Welding Gun features advanced handle design that minimizes operator fatigue. Unit has sealed trigger, rotatable Hi-Viz(TM) neck to optimize weld puddle visibility, and internal trigger leads that prevent trigger cord from tangling with surrounding equipment. Integrated into handle for protection against weld spatter, optional dual schedule switch allows for wire feed speed adjustment while welding.

Conversion Parts help switch between MIG, flux-cored welding.

Bernard Welding Equipment    Beecher, IL 60401
Mar 25, 2010 Centerfire(TM) conversion parts enable companies to switch between MIG and self-shielded flux-cored welding without gun changeover. Units allow Q-Gun(TM) with Centerfire(TM) consumables to be converted to accommodate either process. Using parts, welding operator can replace MIG nozzle, which directs shielding gas, with contact tip holder and insulator, since shielding gas is not needed for flux-cored welding. Removal of MIG nozzle also increases weld joint visibility and accessibility.

MIG Guns and Consumables optimize weld quality.

Bernard Welding Equipment    Beecher, IL 60401
Dec 14, 2009 Rated to 600 A at 100% duty cycle, W(TM)-Series Water-Cooled MIG Guns offer choice of neck style, cable length, handle style, and direct plug connections. Dedicated side-entry coolant channel and strain relief minimize potential for premature gun failure due to kinked coolant lines. Available with 1/8 or ¼ in. contact tip recess, water-cooled Centerfire(TM) Consumables feature spatter shield that optimizes shielding gas flow and keeps spatter from clogging diffuser.

Flux-Cored Welding Gun delivers application versatility.

Bernard Welding Equipment    Beecher, IL 60401
Nov 09, 2009 In addition to 6 cable lengths from 8-25 ft, self-shielded Dura-Flux is available with various neck styles and small trigger guard for maneuverability. Heavy-duty contact tip insulator promotes heat resistance and permits shorter contact tip stickout to prevent arc-out against side walls of deep joints. Other options include large heat shield for blocking radiant heat from welding arc and direct plugs for Miller, Lincoln, Euro, and Tweco 4-wire feeders.

MIG Accessories address comfort and access issues.

Bernard Welding Equipment    Beecher, IL 60401
Sep 29, 2008 Constructed of high temperature silicone rubber tube that slides onto Q-Gun and S-Gun necks, Neck Grip reduces heat exposure and operator fatigue and helps increase operator control for welders who prefer to rest neck of welding gun on their hand or forearm while welding. Neck Coupler allows users to join 2 or more Q-Gun or S-Gun necks consecutively, can be installed in less than 3 minutes, and provides access to difficult-to-reach joints.

MIG Guns are designed for high deposition welding.

Bernard Welding Equipment    Beecher, IL 60401
Aug 08, 2008 Available in 300-600 A models, HD Q and S Series MIG guns feature one-piece straight handle with rubber grip for maneuverability and armor-protected locking trigger with optional dual-schedule switch to provide toughness and reduce operator fatigue. Stay-Tite technology incorporates long-lasting compression fittings and large, tapered neck-to-handle connections to ensure that gun runs cool and delivers consistent electrical current to weld pool.

Welding Gun supports Tweco 4 and Euro connections.

Bernard Welding Equipment    Beecher, IL 60401
May 27, 2008 Rated to 350 A at 60% duty cycle, Dura-Flux self-shielded welding gun accepts flux-cored wire up to 3/32-in. and can be configured with direct plugs for wire feeders outfitted with Tweco 4 and Euro gun connections. Unit includes non-metallic trigger that minimizes heat absorption during welding, trigger guard for maneuverability in confined areas, and sealed microswitch that keeps out dust, dirt, and other contaminants.
