New plunger pump extends portable carpet extractor life.

CAT PUMPS    Minneapolis, MN 55449
Sep 06, 2012 Designed for carpet extractors used in applications from 0.5-2.0 gpm and 100-800 psi, 1XP Series is based on greaseless design that utilizes pumping fluid for lubrication. Wet ends are 100% sealed to ensure contaminants do not leak onto cleaning surface, and design enables retrofit installation into existing extractor while also extending overall pump life and reducing maintenance frequency. Additional applications include misting and hydrostatic testing.

Glycol Dehydration Pumps are built for reliability.

CAT PUMPS    Minneapolis, MN 55449
Jul 18, 2011 Electric engine-driven TEG pumps are designed to supply triethylene glycol (TEG) for natural gas dehydration systems. Providing continuous-duty performance, pumps are rated for flowrates from 2.3-25 gpm, pressures from 100-2,500 psi, and temperatures up to 240°F. Design feature brass or 316 stainless steel liquid-end construction and aids with HAP compliance. Depending on model, drive options include solid shaft, belt, bell, and clutch.

Stainless Steel Triplex Plunger Pump resists corrosion.

CAT PUMPS    Minneapolis, MN 55449
Jan 25, 2011 Constructed with heavy-duty, 316 cast stainless steel head and valves, model 1541 is suited for pumping harsh and aggressive liquids such as sea water, crude oil, waste-water, DI water, and chemicals. Triplex design lends to energy efficiency as well as smooth, low-pulsation performance, while stacked valve design facilitates servicing. Rated at 18 gpm at 1,100 rpm with pressure up to 1,200 psi, pump weighs 55 lb and may be used in portable or stationary installations.

Stainless Steel Plunger Pumps offer corrosion resistance.

CAT PUMPS    Minneapolis, MN 55449
Nov 08, 2010 Featuring continuous-duty triplex design, Models 3501 and 3511 meet requirements of industrial applications where corrosive and aggressive liquids need to be pumped. Model 3501 offers flows to 9 gpm with pressure to 5,000 psi, while Model 3511 features flows to 14 gpm and pressure to 3,000 psi. With 316 SS liquid-end construction, pumps are suited for hydrostatic pressure testing of vessels and pipes, oil recovery, saltwater desalination, and high-pressure chemical dosing.

Stainless Steel Pressure Regulators support 40-75 gpm applications.

CAT PUMPS    Minneapolis, MN 55449
Oct 14, 2010 Model 7375 regulator operates at 75 gpm at 1,000 psi, while 7376 runs up to 75 gpm at 2,000 psi. Both pressure regulators feature flow-thru design permitting compact in-line plumbing, and conical piston and seat design that compensates for pressure spikes. Suited for high-flow, continuous-duty applications such as desalination-reverse osmosis, oil and liquid transfer systems, and heavy equipment cleaning, 316 stainless steel regulators complement 60 Frame triplex plunger pumps.

Plunger Pumps deliver pressures to 3,500 psi for cleaning.

CAT PUMPS    Minneapolis, MN 55449
Sep 27, 2010 With ratings of 5.5 gpm and 3,500 psi, models 5CP5140 and 5CP5140G1 are continuous-duty, industrial pumps offering precise flow setting with various belt-drive options. Model 5CP5140 features dual extended shaft for pulley drive from either side of pump using gas engine or electric motor, while model 5CP5410G1 is fitted with gearbox for mounting onto any standard 1 in. shaft gas engine. Helical gearbox and forged brass head lend to stable operation.

Stainless Steel Pressure Regulators offer 10-75 gpm flow range.

CAT PUMPS    Minneapolis, MN 55449
May 17, 2010 Suitable for variety of liquids including fresh water, sea water, and clean oils, Models 7375 and 7376 feature pressure ranges of 100-1,000 psi and 500-2,000 psi, respectively. Units set system pressure, by-pass unused liquid without interrupting system operation, and protect pump from exceeding set system pressure. Lowering minimum required by-pass flow to 5%, conical piston/seat design assures consistent pressure for multiple pump, gun, or nozzle installation.

Triplex Plunger Pumps offer corrosion resistance.

CAT PUMPS    Minneapolis, MN 55449
Jan 28, 2010 Featuring 316 SS liquid-end for corrosion resistance, Models 7CP6111 and 7CP6171 are suited for pumping liquids such as sea water in small SWRO installations, DI water for misting, or hot water for sterile cleaning systems. Available in either belt-drive or direct-drive models, pumps deliver 10.5 gpm up to 2,000 psi. Units include dipstick for oil level check and STG V-packings to maximize seal life.

Misting Pump suits portable and stationary applications.

CAT PUMPS    Minneapolis, MN 55449
Nov 20, 2009 Available in .13, .25, and .50 gpm configurations with pressures up to 1,000 psi to accommodate variety of nozzles, Model 1CX can be fitted with ¼ or ½ hp single phase motor. Pump features 4-position head mounting, industrial stacked valves, forged brass manifold, and ceramic plungers. Compact brass pressure regulator offers precision pressure setting and over pressure protection. Typical applications include evaporative cooling, insect control, dust suppression, and greenhouse misting.

Triplex Plunger Pump delivers 7,000 psi at continuous duty.

CAT PUMPS    Minneapolis, MN 55449
Apr 28, 2009 For extended durability at 7,000 psi, Model 6801 features duplex stainless steel discharge manifold as well as 316 SS block-style head with optional flushed inlet manifold, providing cooling with high temperature liquids or added lubrication when pumping low lubricity liquids. EPDM, FPM, or PTFE seals are optional for liquid compatibility. Applications include hydrostatic testing, highway and runway cleaning, chemical injection, concrete demolition, and surface prep.
