Jig and Fixture System allows locating and clamping.

Carr Lane Manufacturing Co.    St. Louis, MO 63119
Sep 24, 2012 Comprising clamp, liner bushing, and receiver bushing, Carr Lock™ System allows locating and clamping simultaneously, with twist of hex wrench, for mounting quick-change tooling on subplate. System offers complete interchangeability with all components of Ball Lock® Mounting System, and can be ordered alone or in kits combined with mounting plates.

Quick-Acting Clamps are optimized for holding strength.

Carr Lane Manufacturing Co.    St. Louis, MO 63119
Dec 02, 2008 Heavy-duty shark clamp models CL-500-SHRK, CL-501-SHRK, CL-650-SHRK, and CL-651-SHRK come in 2 sizes and are available with T handle for optimal tightening and leverage of straight handle optimized for comfort and ergonomics. Quick-acting pushbutton lets users slide handle freely in and out to max opening of 5 or 6.5 in., depending on model. Also offered with optional no-mar rubber pads, products suit welding, assembly, repair, woodworking, and general-purpose clamping applications.

Adjustable Ball Lock Pins offer 3 handle styles.

Carr Lane Manufacturing Co.    St. Louis, MO 63119
Mar 11, 2008 Available in steel or stainless steel, Adjustable Ball Lock Pins are manufactured with 4 balls instead of 2 for more distributed ball-pullout force in clamping applications. Units are suitable for pulling 2 components together or to provide adjustable grip length. Available with shank diameters ranging from ¼-1 in., pins offer choice of knob, T, or L handle styles.

Toggle Clamps feature optional safety lock.

Carr Lane Manufacturing Co.    St. Louis, MO 63119
Apr 20, 2007 Available in both steel and stainless steel, low-profile T-Handle Toggle Clamps offer holding capacities from 150-750 lb. All 3 sizes are available with optional safety lock that automatically engages when clamp is closed, then remains locked until manually disengaged by pushing lever before opening. This prevents clamp from being accidentally opened by bumping handle.

Chuck Jaw Plates help machine large, thin-walled parts.

Carr Lane Manufacturing Co.    Saint Louis, MO, MO 63119
Feb 13, 2007 Chuck Jaw Master Plates are made in 3 sections that mount on chuck, and accept variety of machinable jaw segments. They are available for chucks with 10-60 in. dia, in standard height and extra-high versions. Made of aluminum alloy, mounting pattern is machined according to chuck specifications based on make and size.

Mounting Kits reduce setups times for CNC machining.

Carr Lane Manufacturing Co.    St. Louis, MO 63119
Oct 18, 2006 Zero Point Mounting Kits contain all required components to create quick pallet change system for CNC machinery. Speedy Module plates, mounted onto machine table or tooling block, clamp onto nipples attached to bottom of existing fixture plates. Attaching nipples to all fixtures lets users change pallets in seconds. Module plates can also be mounted to inspection machines, making it possible to transfer parts from machining to inspection while maintaining same data points.

Toggle Clamps adjust to workpiece variations.

Carr Lane Manufacturing Co.    St. Louis, MO 63119
Aug 22, 2006 Self-adjusting toggle clamps, with spring-loaded plungers, apply strong, fixed clamping force throughout adjustment range of 0.20 in. Push/pull clamps automatically compensate for workpiece variations while clamping with known force. Spring mechanisms are totally enclosed in plungers and provide force of 100 to 200 lb.

Toggle Clamps incorporate built-in safety lock.

Carr Lane Manufacturing Co.    St. Louis, MO 63119
Nov 21, 2005 Made of steel or stainless steel, CL-200-LPA, CL-300-LPA, CL-400-LPA, and CL-500-LPA feature lock that automatically engages when clamp is closed and remains locked until manually disengaged by pressing lever before opening. This safety lock prevents latch clamp from being accidentally opened by bumping handle. Available in 4 sizes with holding capacities from 700-7,500 lb, all latch-action clamps have threaded U bolt for adjustability and matching latch plate.

Index Plungers offer versatility in setups.

Carr Lane Manufacturing Co.    St. Louis, MO 63119
Apr 27, 2005 Available in straight or tapered versions, Index Plungers are heavy-duty assemblies with retractable spring-loaded plunger. Straight version features cylindrical plunger with slight radius at top and straight bushing. Tapered version offers 15° taper on plunger tip with mating taper on bushing to facilitate alignment. Both types come in rotary cam versions, with standard or flange mounting, or with blank machineable end.

Threaded Detent Pins are held by spring force.

Carr Lane Manufacturing Co.    St. Louis, MO 63119
Dec 16, 2004 Solid alignment pins have ground shank and threaded end for knob handle, and locking balls hold pin in place by spring force. Knob handles can be permanently secured with thread-locking adhesive. Available in stainless steel, products come in standard shank diameters from 3/16-½ in. and various grip lengths. Products require users to push to insert and pull to remove.
