50 Ton Ironworker is equipped with 5 stations.

Scotchman Industries, Inc.    Philip, SD 57567
Aug 13, 2010 Stations of 50514-CM include 50 ton punch station capable of making 13/16 in. hole in ¾ in. material; 4 x 4 x 3/8 in. angle shear; and 14 in. flat bar shear capable of shearing ¾ x 4 in., ½ x 8 in., 3/8 x 10 in., and ¼ x 14 in. Fourth station, rectangle notcher, can notch 2 ½ x 3 x 5/16 in. and/or 2 ½ x 2 ¾ x 3/8 in., while fifth station allows optional pipe notcher to be mounted without removing angle shear. Lock-out tag-out accommodations and all necessary guards are included.

Circular Cold Saw offers mitering, notching capabilities.

Scotchman Industries, Inc.    Philip, SD 57567
Aug 13, 2010 American-made CPO 350 features double clamping and self-centering vise that provides burr-free parts. Along with 135° mitering capability, saw features miter-locking device that automatically stops at 45° left, 90º straight, and 45° right for slotting and notching abilities. Additional features include double reduction gearbox, 2-speed motor that utilizes up to 14 in. dia blade, offering 4 7/8 in. OD round capacity.

Dual-Operator Hydraulic Ironworker features 135-ton capacity.

Scotchman Industries, Inc.    Philip, SD 57567
Aug 05, 2010 Model DO 135 ironworker has 2-pump hydraulic system that ensures both operations have full hydraulic pressure and speed. It has 2 valves, 2 stroke controls, 2 remote foot pedals, and 4 built-in stations. With 12 in. throat depth, machine can punch 1 11/16 in. hole in 1 in. material. Machine also features 6 x 6 x ½ in. angle shear and rectangular notcher that can notch 3 x 5¾ x ½ in. material. Its 24 in. flat bar shear features low rake angle and can shear up to 1 x 12 in. and ½ x 24 in. material.

Hydraulic Ironworker offers variety of standard, optional features.

Scotchman Industries, Inc.    Philip, SD 57567
Aug 05, 2010 Complete with 2 valves, 2 stroke controls, and 2 remote foot pedals, Dual Operator 95/140 has hydraulic system designed with 2 pumps for operational consistency. It has 95-ton capacity punch and 9 in. throat depth, which can punch 1 3/16 in. hole in 1 in. material. Along with 4 built-in stations, system offers 6 x 6 x ½ in. angle shear, rectangular notcher that can notch 3 x 4 x ½ in. material, and 24 in. flat bar shear that can shear up to 1 x 8 in. and 3/8 x 24 in. material.

Horizontal Band Saw has double swing design.

Scotchman Industries, Inc.    Philip, SD 57567
Aug 05, 2010 Able to swing 45° right or 60° left, 20 in. DS-20 horizontal band saw comes with quick-slide vise, 1¼ in. blade, saw guides with carbide inserts, and remote control console. Hydraulic clamping and head lift combine to provide semi-automatic cycle control Respective capacities for this general-purpose band saw at 90°, 45°, and 60° are 14 in. high x 20 in. wide, 14 x 14 in., and 14 x 10 in. Minimal maintenance is required.

Measuring System mounts to metal or wood working machinery.

Scotchman Industries, Inc.    Philip, SD 57567
Oct 05, 2006 Enabling accurate setting of material length, CPO 350 Scotchman® Advanced Measuring System allows feeding of material in 4-24 ft lengths from left to right or right to left. Loc Stop and Multi-Loc systems are manufactured using stainless steel investment casting, and do not slip.

Grinder Notcher comes with dust extractor.

Scotchman Industries, Inc.    Philip, SD 57567
Sep 12, 2006 Featuring 6 in. wide belt, GN 6 DE is designed for tube and pipe notching of materials with diameters from 3/4-6 in. and adjustable angles between 30° and 90°. It can be converted to traditional grinder by exchanging contact roller with rubber back up wheel. Also available without dust extractor (GN 6), product features 5 hp motor with safety lockout, motor protection switches, low-voltage coils, and rubber drive wheels for no-slip aggressive grinding.

Circular Cold Saw features rigid column design.

Scotchman Industries, Inc.    Philip, SD 57567
Sep 12, 2006 Able to miter 45° and cut up to 4 in. solid tool steel, semi-automatic Model CLM 350 features completely hydraulic down stroke, up stroke, feed pressure reducing valve, and material clamping. Five horsepower saw is equipped with flood coolant system, separate coolant reservoir and chip collection drawer, electric foot pedal, emergency lock-out tag-out, one blade, and 30 in. material stop.

Centerless Belt Grinder uses abrasive or fiber belts.

Scotchman Industries, Inc.    Philip, SD 57567
Sep 12, 2006 Used for external cleanup and finishing of material ½-4 in. diameter, 3 in. Model CG 3 can be converted to traditional grinder. Power head has feed rate and pressure controls and is easily adjustable. Grinder includes integrated coolant system to control sparks and dust, and can provide variety of finishes on materials ranging from aluminum to stainless steel.

Automatic Feed System helps eliminate waste.

Scotchman Industries, Inc.    Philip, SD 57567
May 30, 2006 Advanced Feed System, coupled with circular cold saw, turns semi-automatic machine into automated production machine. It automatically moves material to position, clamps material, and cycles machine with ±0.004 in. repeatable accuracy. Operator can manually enter dimensions into controller, pull cut list from controller, or download information from PC. System can be used as programmable stop system or fully automatic programmable push feed system with optional material clamp.
