OCXO includes electronic frequency control.

Connor-Winfield Corp., The    Aurora, IL 60505
Apr 26, 2013 Housed in 36 x 27 x 13.46 mm hermetically sealed CO-8 package, 12 Vdc Model OX200-SC provides 10 MHz LVCMOS output and is designed for applications such as IP Backhaul using IEEE1588 PTP Master Clock that requires high frequency stability. Ovenized third overtone SC Cut crystal oscillator features frequency stability of ±1.5 ppb within temperature range of 0–70°C. EFC can vary frequency ±0.2 ppm over 0–4 V. Typical phase noise levels range from -85 dBc/Hz at 1 Hz to -150 dBc/Hz at 10 kHz.

Frequency Translator/Jitter Filter translates inputs between 8-250 MHz.

Connor-Winfield Corp., The    Aurora, IL 60505
Apr 18, 2012 SFX-525G frequency translator and 20 Hz jitter attenuator translates an input between 8 kHz to 100 MHz to output frequencies between 8-250 MHz. It provides jitter filtered, wander following output signal synchronization to superior GPS, Stratum or peer input reference signal and supports FEC rates such as 15/14 and 255/237. IC is designed for use in line and service termination cards to provide phase-locked synchronization for network equipment.

Rugged GPS Disciplined Clock ensures precision timing.

Connor-Winfield Corp., The    Aurora, IL 60505
Aug 04, 2011 With Stratum 1 time source, 125 Series Xenith TBR (Model FTS500) consists of OCXO-based enclosed GPS disciplined clock and timing device for DVB, DAB, wireless communication infrastructures, time-stamping, or any other critical timing applications. This GPS-driven, mixed-signal PLL provides 1 pps CMOS output and generates 10 MHz SINE output from low-jitter VCXO. Supplied in aluminum housing measuring 106 x 125 x 56 mm, solution is G.811 compliant (GPS locked) and G.812 Holdover compliant.

Crystal-Based Oscillators offer high frequency stability.

Connor-Winfield Corp., The    Aurora, IL 60505
Jun 15, 2011 Featuring 5-40 MHz frequency range, IEEE 1588 compliant OH300 series OCXOs are offered with frequency stabilities of ±10, ±20, and ±50 ppb. They are available with LVCMOS, HCMOS of Sine output, along with electronic frequency tuning, and also feature low phase noise and phase jitter. Units operate from 3.3-5.0 Vdc, while power requirements are 3 W over commercial temperature range and 4.5 W over industrial temperature range. All are contained in surface-mounted, 22 x 25 x 12.7 mm package.

Timing Chips suit SDH/SETS, SONET, and synchronous Ethernet.

Connor-Winfield Corp., The    Aurora, IL 60505
Nov 19, 2010 Offering 3 V operation, STC5420 Series chips accept 12 clock reference inputs from 8 kHz to 125 MHz and generate 10 synchronized clock outputs from 2 kHz to 312.5 MHz in LVCMOS, LVPECL, or LVDS. They include independent timing generators that operate in freerun, synchronized, pseudo-holdover, and holdover mode. Reference inputs are individually monitored for quality, and devices also provide programmable compensation for phase delay between master and slave unit in 0.1 nsec steps.

Ovenized Oscillators offer stability from ±20 to ±100 ppb.

Connor-Winfield Corp., The    Aurora, IL 60505
Nov 02, 2010 Available with LVCMOS outputs, DOC Series OCXOs and OCVCXOs feature 3.3 Vdc operation and optional Electronic Frequency Tuning. RoHS-compliant, lead-free units are available in temperature ranges of 0-70°C, -20 to 70°C, and -40 to 85°C. Housed in 9.1 x 14.1 mm SMT package, oscillators are suited for cellular base stations, test equipment, synchronous Ethernet, and VSAT applications.

GPS Disciplined Oscillator includes holdover functionality.

Connor-Winfield Corp., The    Aurora, IL 60505
May 27, 2010 Providing 1 PPS CMOS output, Model FTS375 generates 10 MHz CMOS and 10 MHz SINE output from intrinsically low jitter voltage controlled crystal oscillator. Mixed signal, phase lock loop device can lock to 10 MHz reference derived from on-board GPS receiver, or to external 10 MHz or 1 PPS reference. Alarms are provided to indicate Loss-of-Lock, Holdover, and Antenna Fault. Housed in 3.937 x 1.969 x 0.708 in. package, device operates from +3.3 V supply at temperatures from 0-70°C.

Clock Generator targets GPS-based timing applications.

Connor-Winfield Corp., The    Aurora, IL 60505
Apr 15, 2010 Operating from +3.3 V supply, TCXO-based Model FTS250 provides 1 pps CMOS output and generates 10 MHz CMOS and 10 MHz SINE output from voltage controlled crystal oscillator. Mixed signal PLL device can lock to 10 MHz reference derived from onboard GPS receiver, or to external 10 MHz or 1 pps reference. Alarms are provided to indicate Loss-of-Lock, Holdover, and Antenna Fault. Housed in 2.9 x 1.725 x 0.368 in. package, generator includes serial I/O for access to NMEA messages from GPS receiver.

Subminiature TCXO comes in 3.2 x 2.5 mm SMT package.

Connor-Winfield Corp., The    Aurora, IL 60505
Feb 18, 2010 Using analog temperature compensation, D32G series is capable of holding sub 1 ppm stabilities over -30 to 85°C temperature range. Features include 3.3 Vdc operation, clipped sinewave output logic, and frequency stability of ±0.50 ppm. RoHS compliant TCXO offers low phase noise and low jitter of less than 1 pS rms. Product is suited for use in GPS receivers, instrumentation, Femtocell, FTTH, and FTTC applications requiring tight stability over broad temperature range.

OCXOs and OCVCXOs offer high stability.

Connor-Winfield Corp., The    Aurora, IL 60505
Nov 09, 2009 Series OH200 OCXOs/OCVCXOs require 3 W over 0-70°C temperature range and 4.5 W over -40 to +85°C range, and provide temperature stabilities from 6-20 ppb absolute over both ranges. Products support frequencies of 5.0-40.0 MHz and have warm up times of 5 min to 0.10 ppm of final frequency. Available in LVCMOS and HCMOS outputs, they offer low phase noise/Allen Variance specifications. Units are housed in 1.1 x 1.4 x 0.5 in., hermetically sealed package.

Surface Mount TCXOs suit clipped sinewave applications.

Connor-Winfield Corp., The    Aurora, IL 60505
Oct 12, 2009 Capable of holding sub 1 ppm stabilities over -30° to 85°C temperature range, D53G Series sub-miniature precision TCXOs suit Stratum 3, GPS receivers, instrumentation, Femtocell, FTTH, and FTTC applications. Available in 5 x 3.2 mm surface mount package, units feature 3.3 Vdc operational voltage, frequency stability at ±0.50 ppm, and less than 1 pS RMS jitter. TCXOs are RoHS compliant, and come in tape and reel packaging.

GPS Timing Receiver targets WiMax applications.

Connor-Winfield Corp., The    Aurora, IL 60505
Sep 11, 2009 Designed for synchronization and timing in WiMax applications, surface mount TiMax Wi125 features programmable NCO oscillator that outputs synthesized frequency up to 30 MHz, which is steered by GPS receiver. Self-survey mode allows receiver to enter position hold mode, allowing accurate timing to be continued with only 1 satellite being tracked. Additional features include phase alignment of 1 PPS/10 MHz and GPS/UTC time/scale synchronization to 25 ns RMS.

Crystal Controlled Oscilllators offer 2.5 or 3.3 V operation.

Connor-Winfield Corp., The    Aurora, IL 60505
Aug 28, 2009 Housed in 5 x 7 mm surface mount package, LM Series provides LVDS differential outputs with enable/disable function, while PM Series provides LVPECL differential outputs. Frequency range of 25-670 MHz covers applications in SONET, GE, FC, G.709, OTU1, OTU2, 10GE copper and fiber, 10GEFC, SAS, HDVUSA, HDVEUR, and DDR clock rates. Operating from -40 to 85°C, RoHS-compliant oscillators feature frequency stabilities as low as 20 ppm and low jitter of 0.6 psec RMS typical.

Synchronous Clock Generator is RoHS compliant.

Connor-Winfield Corp., The    Aurora, IL 60505
Jul 08, 2009 Designed for SONET/SDH/ATM applications, SFX-800G translates one input greater than 1 MHz into one of 8 selectable output frequencies between 10 MHz and 1.125 GHz. It is available as 3.3 V high precision PLL, and comes in 1.2 x 1.0 x 0.285 in. surface mount package. It supports most FEC rates such as 15/14 and 255/237, and provides jitter filtered, wander following output signal synchronized to Stratum or peer input reference signal.

TCXOs/VCTCXOs are offered in tape and reel packing.

Connor-Winfield Corp., The    Aurora, IL 60505
Jun 10, 2009 Available in sub-miniature 5 x 3.2 mm SMT Package, RoHS Compliant M Series TCXOs/VCTCXOs are designed for use in Stratum 3 applications, GPS receivers, instrumentation, femtocell, and FTTH and FTTC. They offer 3.3 and 5.0 V operation, and have temperature ranges of 0 to 70°C and -40 to 85°C. Frequency stabilities are ±0.28 ppm with Stratum 3 Holdover and ±0.50 or 1.00 ppm. Outputs are available as LVCMOS or clipped sine wave.

Oscillators are available in 5 x 7 mm surface mount package.

Connor-Winfield Corp., The    Aurora, IL 60505
May 04, 2009 With operating frequency range between 40-200 MHz, XH7 and XH9 LVCMOS, fixed frequency crystal controlled oscillators suit applications in COTS military, aerospace, and industries where operating conditions involve high shock, vibration, and wide temperature range. Product has operating voltage of either 2.5 or 3.3 V, frequency stability at 50 and 100 ppm, jitter of less than 1 pS RMS, max subharmonics of -70 dBc, and max perturbations of 3 ppm.

OCXO comes in 9 x 14 mm SMTpackage.

Connor-Winfield Corp., The    Aurora, IL 60505
Apr 14, 2009 FC100 Series of 3.3 V CMOS or Clipped Sinewave OCXO is suited for 3G, Stratum 3, GPS and femtocell applications in standard frequencies of 10, 13, 19.2, 19.44, 20, 26 and 38.88 MHz. Device is stable at less than 200 ppb frequency offset over 0-70°C with low phase noise of -145 dBc at 10 kHz offset for 20 MHz carrier frequency.

IC offers single chip synchronous clock solution for SETS.

Connor-Winfield Corp., The    Aurora, IL 60505
Aug 21, 2008 Fully compliant with ITU-G.813 and Telcordia GR1244 and GR253, Model STC5230 offers single chip solution for timing source in SDH, SONET, and Synchronous Ethernet network elements. It accepts 12 reference inputs and generates 9 independent synchronized output clocks, and offers 2 independent timing generators, T0 and T4, for Synchronous Equipment Timing Source (SETS). Available in TQ100 package, device operates with external OCXO or TCXO as its MCLK at 20 MHz.

OCXOs and VCOCXOs offer stabilities of ±0.05 to ±0.25 ppm.

Connor-Winfield Corp., The    Aurora, IL 60505
Aug 12, 2008 Available in both 14 pin DIP (PF1 Series) and 14 x 20 mm SMT (PF2 Series), OCXOs and VCOXCOs have frequency range of 6.4-40 MHz. RoHS compliant, lead free units offer 3.3 or 5 V operation, LVCMOS or HCMOS output logic, and jitter of less than 1 pS rms. Models PF15 and PF25 have 0-70°C temperature range, while PF16 and PF26 operate over -40 to 85°C.

Telecom TCXOs, VCTCXOs come in miniature package.

Connor-Winfield Corp., The    Aurora, IL 60505
Jul 28, 2008 Supplied in 5.0 x 7.0 mm SMT package, T5xx Series and T6xx Series TCXOs and VCTCXOs are designed for use in S3 Telecom applications. Through use of analog temperature compensation, devices are capable of holding sub 1-ppm stabilities over commercial or industrial temperature ranges. All models are RoHS-compliant, operate from 3.3 V, and meet ±4.6 ppm accuracies for 20 years. They feature LVCMOS or clipped sinewave output logic and tri-state enable/disable.
