Rectangular Power Connectors are offered with hoods, housings.

2E SysCom, Inc.    Framingham, MA 01702
Feb 24, 2011 Rated at 10 A and 230/400 V per pin, Heavy Duty Connectors can be supplied with hoods and housings featuring protection level ratings of IP65/IP68. Rectangular connectors, used in equipment that requires electrical and signal connections, are internationally recognized standard connectors covered by DIN VDE 0627/0110 and DIN EN 61984/6198 specifications. DIN 41612 Power Connectors, DIN 41617 Headers, as well as IGBT Connectors and Cable assemblies are also available.

Male/Female 48-Pin DIN Connectors are rated at 6 A per pin.

2E SysCom, Inc.    Framingham, MA 01702
Mar 27, 2009 F Series female connector is available in standard card cage-mountable as well as low-profile back plane versions. Pin configurations include faston forks, which can have contacts soldered onto pin or connected to discrete wiring via faston crimp contact. Solder eyelet wire wrap and board solder pins are also available. Connector body, available with integrated coding and screw on mounting ears, is made of polyester PBT (UL 94 V-0). Contact plating in mating area is Au/Sn.

Connector and Cable Assembly are suited for IGBT modules.

2E SysCom, Inc.    Framingham, MA 01702
Jul 30, 2008 Connector and cable assembly are designed for attaching to spade terminals on IGBT modules. Connectors have integrated automatic locking clips and are suitable for 2 faston tabs 2.8 x 0.5 mm with available grid spacings of 4.0, 4.7, and 6.0 mm. Color coded red, black, grey, and white, wires are 20 AWG stranded, rated at 600 V, and 125°C, separated by spacer, and terminated in 4 pin PCB mount connector.

Power Connectors offer 20 A load capacity per pin.

2E SysCom, Inc.    Waltham, MA 02453
Feb 01, 2008 Based on DIN 41612 standard, Type EMSP male and female connectors are individual modules, constructed of 2- and 3-pin connector bodies that can be clipped together side-by-side for custom configuration. Backplane half consists of female connector, which provides complete protection for hot pin. Male connector has solder pins at 90° to contact pins and 2 pins/contact for board hole diameters of 1.6 mm. Air and creepage distances allow for operating voltage of 750 V.
