Absolute Multi-Turn Rotary Encoder has DRIVE-CLiQ interface.

TR Electronic, Inc.    Troy, MI 48083
Dec 05, 2012 Along with magnetic detection and M12 connector, CMV36-M features DRIVE-CLiQ open interface which lets users select measuring system that best fits application. Encoders using measurement techniques, such as magnetic/inductive sensors, can also be connected through DRIVE-CLiQ. Due in part to reading of specific data from electronic rating plates of drive components, encoder features error-free parameterization of drive as well as accelerated commissioning and diagnostics.

Multi-Turn Rotary Encoder integrates SERCOS III interface.

TR Electronic, Inc.    Troy, MI 48083
Dec 05, 2012 Along with 27-bit resolution (30-bit optional), CEV58 ES3 features SERCOS III interface with bump-less physical layer single-fault recovery. SERCOS III allows insertion and configuration of devices into network when cyclic communication is active and is backwards-compatible with previous versions of SERCOS. Optical scanning technology provides 13 arc sec of precision, while compact M12 connectors and various shaft and mounting flange configurations facilitate application integration.

EtherCAT Absolute Encoder offers parameter setting possibilities.

TR Electronic, Inc.    Troy, MI 48083
Nov 12, 2012 Available with fully programmable electronic resolution, multi-turn absolute encoder with EtherCAT offers position and speed readouts. Available shaft types include solid, blind, hollow through, and integrated coupling, and modular construction enables mechanical customizations. Operating from 11–27 Vdc supply, encoder works from 0 to +60°C as standard (-20 to +70°C optionally) and is IP65 rated when used with screwed on mating connector and/or screwed together cable gland.

Absolute Encoders operate with SIL 3 safety functions.

TR Electronic, Inc.    Troy, MI 48083
Oct 11, 2012 With low probability of failure, CDx Series is suited for applications requiring redundancy. Series includes 75 mm CDV solid shaft model and 75 mm CDH hollow through shaft option. Both have 2 channels and are available with either SSI or Fieldbus interfaces. Models with SSI feature 2 redundant SSI interfaces – master system and safety system, while models with PROFIsafe protocol consist of dual channel optical and magnetic scanning systems. All have IP54 rating and operate from 0–60°C.

Tool Detection System scans for presence and scale.

TR Electronic, Inc.    Troy, MI 48083
Aug 10, 2012 Suitable for turning and milling machines as well as all machining centers, BQS Tool Detection System monitors tools and workpieces for tool presence, tool breakage, and tool ejection. System also performs object recognition, free space monitoring, and process monitoring, and checks for position definition and clamping errors. Housed in anodized aluminum with multi-stage sealing system and IP68 rating, system features fixed starting position with scanning angle of 15-300° on both sides.

Absolute and Incremental Encoders feature IP69K rating.

TR Electronic, Inc.    Troy, MI 48083
Jul 16, 2012 Measuring 36 mm in diameter, IP69K Encoders are built to withstand strict and harsh wash-down conditions such as extreme heat, pressure, and caustic nature present in food and beverage industries. Units feature magnetic shaft coupling for external shaft installations, protective coating of PCB, and optional separate bearing. Completely wear-free, encoders have standard SSI Interface with dual redundant SSI output available.

Distance Measurement System supports ProfiNET communications.

TR Electronic, Inc.    Troy, MI 48083
Jun 11, 2012 ProfiNET LE-200 laser distance measurement system provides communication option for users looking for real-time, closed loop distance feedback application solutions. Incorporating phase-shift differential technology, unit delivers accurate (±2 mm) and reliable positioning technology over 0.2-240 m range. Cooling and heating options are available for extreme environments, and other available protocol options include EtherNET/IP, DeviceNET, Profibus, Interbus, and CAN.

Absolute Encoders use EtherNet/IP interface.

TR Electronic, Inc.    Troy, MI 48083
May 09, 2012 Combining integrated switch, modular construction for mechanical customizations, and extensive parameter configurations via network, CEx58 Series features optional working temperature of -20 to +70°C and IP65 protection class. EtherNet/IP treats network devices as series of objects and uses Common Industrial Protocol to access these objects. CIP offers wide range of messages and services to capture production automation data.

Wireless Sensor System targets industrial automation market.

TR Electronic, Inc.    Troy, MI 48083
Feb 06, 2012 By inductively supplying power and signals from fixed part to moving part, across air gap, PowerGap(TM) eliminates need for cables, connectors, and slip ring solutions. System features wear-free, non-contact design, which can transmit wirelessly through non-metallic barriers. Available in Standard M18, M30, and 90 x 90 mm square housings, PowerGap has up to 64 inputs and 32 outputs of discrete I/O and is DeviceNet, EtherNet/IP, and RS232 compatible.

Rotary Encoders are designed for industrial automation.

TR Electronic, Inc.    Troy, MI 48083
Sep 17, 2009 SENSEable(TM) encoder product line includes incremental and absolute encoders designed for industrial automation. Customers have ability to choose from wide variety of interfaces including serial, parallel, SSI, fieldbus, and all leading Industrial Ethernet protocols. Devices run on TR's optical and magnetic technologies and are available with shafted, hollow shaft, blind-shaft and integrated coupling configurations.
