Emulsifier and Wet Mill suits liquid pharmaceutical processing.

Quadro Engineering Corp.    Waterloo, N2V1A1
Dec 24, 2010 Accommodating liquid pharmaceutical processors interested in submicron emulsions, suspension milling, and micronization, Ytron® HV0-Emulsifier and Wet Mill provides benefits of high velocity (HV) milling at inline process capacity of 1-5 Lpm. There are 3 models, ranging from 7.5-60 hp, with capacities of up to 285+ Lpm. Each uses energy optimized tooling that operates at tip speeds to 70 m/sec. Sanitary high-speed mechanical seal eliminates potential trap areas around rotor shaft.

Sifter Delumper handles up to 110,000 lb/hr.

Quadro Engineering Corp.    Waterloo, N2V1A1
Apr 16, 2010 Intended for food/pharmaceutical manufacturers, FlexSift S10 handles small batch operations, while FlexSift S30 is designed for larger batch/continuous flow operations. Units security screen, delump, and discharge, all without need for product feeder. Flush ground welds facilitate cleaning, while vibration-free design enables sifters to be coupled with most bulk bag unloaders and mixer dischargers. Both can be customized to suit many applications.

Wet Mill has high-shear design.

Quadro Engineering Corp.    Waterloo, N2V1A1
Apr 15, 2010 Employing rotor-stator suspension milling technology, high shear Ytron HV-Wet Mill is available in 3 different models ranging from 25-125 hp with capacities up to 150 gpm. Energy optimized tooling operates at tip speeds up to 70 m/sec with low power consumption, while sanitary high-speed mechanical seal eliminates potential trap areas around rotor shaft, optimizing clean-in-lace results. Options include selection of motors, controls, and portable bases.

Dual-Purpose Machine can be used for milling and screening.

Quadro Engineering Corp.    Waterloo, N2V1A1
Apr 15, 2009 Quadro® ComilSift allows processors to go from milling applications up to 15,000 lb/hr to security screening and delumping applications up to 99,000 lb/hr. Milling mode efficiency is optimized due to infeed diameter size, while positive 360º discharge of security screening mode segregates and retains impurities and other foreign materials to accelerate sifting times. Construction facilitates integration into process streams, possibly eliminating need for feeding equipment.

Emulsifiers utilize submicron size reduction technology.

Quadro Engineering Corp.    Waterloo, N2V1A1
Mar 31, 2009 Quadro® HV-Emulsifier Series features 3 different models ranging from 20-125 hp depending on desired capacity, up to maximum of 250 gpm. All models utilize energy optimized tooling that operates at tip speeds up to 60 m/sec with low power consumption. Sanitary high-speed mechanical seal eliminates potential trap areas around rotor shaft for optimal CIP results. Various other equipment options are available including selection of motors, controls, and portable bases.

Jet Mixer suits sanitary in-tank agitation applications.

Quadro Engineering Corp.    Waterloo, N2V1A1
Jan 08, 2009 Capable of producing strong axial flow patterns and uniform liquid velocity throughout mixing vessel, Ytron® C-Type Jet Mixer complies with 3-A Sanitary Standards. Side entry tank/silo mixer offers CIP operation with line-of-sight access to all product contact areas and motor flange adapter, enabling quick sight checks for leak detection and seal maintenance. It is available in 2 models ranging from 7.5-20 hp depending on desired capacity/batch size, up to maximum of 80,000 gal.

Vibration Free Sifter facilitate security screening of APIs.

Quadro Engineering Corp.    Waterloo, N2V1A1
Dec 23, 2008 Quadro® FlexSift, in-line, high-capacity, vibration-free sifter can be integrated below existing equipment or can be used as stand-alone unit. It is able to security screen APIs with varying screen/mesh sizes ranging from .006 in. for some products, with typical applications in .011-.009 in.

Shear Pumps can be cleaned and sanitized in place.

Quadro Engineering Corp.    Waterloo, N2V1A1
Sep 23, 2008 Targeting food and beverage industry, ShearFX Series features 4 different models ranging from 10-75 hp with capacities up to 250 gpm. Multiple tooling styles are available, allowing balance between shear energy and pumping efficiency. Design of pump and tooling offer ease of installation and maintenance while meeting stringent hygienic standards for being CIP-able and SIP-able. Various other options are available including selection of motors, controls, and portable bases.

Benchtop Homogenizer features digital speed control.

Quadro Engineering Corp.    Waterloo, N2V1A1
Nov 29, 2007 Available in 4 models ranging from ¾ to 1¾ hp, BT Series benchtop homogenizer can process sample volumes varying from 5 mL to 40 L at tip speeds up to 60 m/sec, depending on tooling selection. Featuring quick connect generator design and tight rotor-stator clearances, unit is offered with variety of sealed chamber assemblies to safely contain hazardous samples. Generator deflector head facilitates sample movement for large volume and high viscosity formulations.

Mixing Unit includes high shear homogenizer.

Quadro Engineering Corp.    Waterloo, N2V1A1
Oct 13, 2006 Suited for mixing, dispersion, and homogenizing systems, Quadro Mixing Unit with Serendip HSH features rotor tip speeds up to 197 ft/s under vacuum processing conditions. Unit delivers no cavitation due to processing staging and has gentle pumping discharge using low-shear force. Typical applications include toothpaste, creams/lotions, adhesives, hair gels/mousses, antacids, sauces/syrups, liquid hand soap, and car polishes/waxes.
