Submerged Arc Flux for Stainless Steel and Nickel Alloys.

Lincoln Electric Co. Inc., The    Cleveland, OH 44117
May 06, 2013 Designed for specialty stainless steel and nickel grades, such as 625, 347, duplex, and super duplex, Lincolnweld® P2000™ neutral basic flux produces sound welds with optimal slag removal and bead appearance. This SAW flux, which is available in 50 lb plastic bag, also exhibits resistance to moisture pickup. When welding with this product, use of stainless steel and nickel-grade wire containing Niobium (Nb) is recommended.

Submerged Arc Flux suits offshore welding applications.

Lincoln Electric Co. Inc., The    Cleveland, OH 44117
Apr 15, 2013 Accommodating applications requiring high strength after extensive post-weld heat treatment of up to 30 hr, Lincolnweld® 812-SRC™ carbon-neutral flux provides smooth bead appearance and exhibits moisture resistance. When welding with Lincolnweld LA-84, this flux will produce weldments with hardness values below 250 Hv10 and less than 1% nickel. Available in 50 lb plastic bag, this SAW flux is designed for offshore welding and NACE applications.

Welding Brushes are designed for different base metals.

Lincoln Electric Co. Inc., The    Cleveland, OH 44117
Mar 04, 2013 Radius™ Welding Brushes clean base material before welding and between each pass. Featuring steel-wire bristles, brushes for stainless steel include toothbrush-style 3 x 7 row brush, 2 x 9 row brush with slightly curved handle, and 3 x 19 row brush. For aluminum, toothbrush-style 3 x 7 row brush and 2 x 9 row brush with slightly curved handle have brass-wire bristles. With tempered-steel bristles, brushes for carbon steel include 3 x 19 row brush and 4 x 16 row brush with curved handle.

Orbital Welding System operates in confined spaces.

Lincoln Electric Co. Inc., The    Cleveland, OH 44117
Feb 20, 2013 With all components housed in APEX™ Mobile Workstation, APEX™ 2100 features low profile HELIX™ T55 Weld Head and gear-driven track ring system. Controller with pendant delivers integrated and synchronized system to monitor, adjust, and control welding parameters throughout welding process, while capturing all welding information and data for analytical and statistical reporting. Cool Arc® 55 Water Cooler, integrating with Power Wave® S500 multi-process power source, cools torches up to 500 A.

Flux-Cored Wires offer high deposition rates.

Lincoln Electric Co. Inc., The    Cleveland, OH 44117
Feb 18, 2013 Available in standard diameters of 0.045, 0.052, and 1/16 in., UltraCore® HD-12C and UltraCore® HD-12M are E71T-12C-JH8 and E71T-12M-JH8 flux-cored wires offering weld deposition rates of more than 14 lb/hr out-of-position. UltraCore® HD-12C is optimized for use with 100% CO2, while UltraCore® HD-12M uses mix of 75-80% Ar/balance CO2. Both mild steel FCAW-G products offer low-temperature-impact toughness exceeding 30 lbf-ft at -40°F.

Metal-Cored Wire suits semiautomatic and robotic applications.

Lincoln Electric Co. Inc., The    Cleveland, OH 44117
Jan 21, 2013 Available in .045, .052, and 1/16 in. diameters, Metalshield® MC®-80Ni1 produces H4 diffusible hydrogen weld deposits in structural and heavy fabrication applications that require tensile strength of 550 MPa. Silicon island management minimizes slag and eases slag removal, while deoxidizing agents minimize weld clean up. In addition to low spatter and optimal arc stability, low-alloy wire features low temperature impact properties with Charpy V-Notch test results exceeding 35 ft-lbf at -60°F.

Semiautomatic Wire Feeder comes with compatible welding gun.

Lincoln Electric Co. Inc., The    Cleveland, OH 44117
Jan 14, 2013 Suitable for shipbuilding, offshore, construction, and pipe welding operations, Activ8™ is available in One-Pak® configuration that includes Magnum® PRO Curve™ 300 gun and 15 ft cable. Feeder is designed for 8 in. spools and is compatible with any DC CV and/or CC power source. Rated at 330 A at 60% duty cycle, Active8™ feeds self-shielded FCAW or FCAW-G and GMAW gas-shielded wires at 50–800 ipm. It handles GMAW wires from .023–.052 in. dia and FCAW wires from .035–5/64 in. dia.

Collapsible Robotic Welding Cell aids student and workforce training.

Lincoln Electric Co. Inc., The    Cleveland, OH 44117
Dec 03, 2012 Robotic Welding Education Cell 2.0, featuring collapsible 2,000 in.² max work surface area, has shielding gas bottle rack/storage, fume extraction system mounting, and welding robot. Mounted on wheels, lightweight unit fits through standard doorway and also has AutoDrive® 4R100 wire feeder, Magnum® PRO robotic welding torch and consumables, and SuperArc® L-56® GMAW welding wire. Unit includes production monitoring software and is designed to be training tool in classrooms and welding labs.

Mobile Virtual Reality System provides arc welding training.

Lincoln Electric Co. Inc., The    Cleveland, OH 44117
Nov 26, 2012 Supplied in portable package, VRTEX® Mobile delivers hands-on, entry-level training solution that is consistent with industry methodology and evaluation criteria. With universal gun handle design, system offers pre-installed basic GMAW (MIG) package and optional SMAW stick add-on package, providing training for flat plate, 2F/3F joints, and 1G, 2G, and 3G grooves. VRTEX® Mobile measures and records students’ training results in real-time to help identify welding deficiencies and strengths.

Welding Gear Pack contains all necessary PPE.

Lincoln Electric Co. Inc., The    Cleveland, OH 44117
Oct 30, 2012 Available in sized packages ranging from medium to 2XL, Premium Welding Gear Ready-Pak® contains top-grade personal protection equipment for welding and other fabrication tasks. Each kit includes VIKING™ 3350 Series variable shade 6–13 black helmet, Shadow™ split leather sleeved jacket, leather MIG/Stick welding gloves, and leather SteelWorker® gloves as well as Finish Line™ clear safety glasses, split leather flame-resistant welding sleeves, flame resistant doo-rag, and industrial duffle bag.
