Engineering Software focuses on evaluation of terminal data.

EPLAN Software und Service GmbH & Co. KG    , -
Nov 15, 2012 Combining engineering with simultaneous creation of informative documentation, EPLAN Platform 2.2 provides graphical macro selection, smart terminal analysis, and automatic termination points when copying sections of circuit. Rapid filters in project data navigators, comprehensive parts data exchange, and extended terminal design optimize speed in project processing. With software, switching states of terminals stored in circuit diagram can be automatically illustrated graphically in reports.

Cable Planning Software provides 2D layout of production area.

EPLAN Software und Service GmbH & Co. KG    , -
Oct 29, 2012 Available with EPLAN Platform 2.2, FieldSys add-on module allows cable laying routes to be configured to scale. Planning tool includes routing, database-assisted management of cable routes, and automatic data analysis to accelerate processes, facilitate assembly, and ensure efficient system planning. Module is based on 2D machine/plant layout which can be read into EPLAN in DWG or DXF format. Based on routing information, EPLAN FieldSys generates comprehensive cable reports that aid in assembly.

CAE Software facilitates control cabinet design, assembly.

EPLAN Software und Service GmbH & Co. KG    , -
Sep 05, 2012 Copper add-on module for EPLAN Pro Panel Professional enables design, configuration, and virtual assembly of control cabinets as well as necessary busbar systems. Information from Rittal Power Engineering planning tool can be utilized to fit necessary Rittal system components into virtual 3D model. Module allows planning of various components based on Ri4Power solution from Rittal or RiLine60 modular busbar system and TS 8 control cabinet.

CAE Software integrates fluid engineering, mechanical design.

EPLAN Software und Service GmbH & Co. KG    , -
Jul 16, 2012 Fostering design standardization, Eplan Fluid lets fluid engineers save and re-use frequently used subsystems as macros. This accelerates engineering while safeguarding quality. Together with electrical engineering, workflow helps reduce errors and lets engineer focus on selection and dimensioning of components, fluid system connections, and correct positioning. Fluid symbols, 3D data, and electrical actuation are directly linked to parts list and technical specifications of equipment.

Engineering Data Portal includes data for 250,000 devices.

EPLAN Software und Service GmbH & Co. KG    , -
Mar 30, 2012 EPLAN Data Portal v2.1 provides master data for 250,000 components from nearly 50 manufacturers along with schematic macros, multilingual parts information, preview images, and documents. Users can access live data and import parts/macros into component library and drag and drop parts/macros into their designs. Manufacturers can store standard parts data on portal and also link product configurator for components that are changing rapidly.

Plant Maintenance Software documents operational sequences.

EPLAN Software und Service GmbH & Co. KG    , -
Oct 11, 2011 Eplan Operational Sequence documents functional timeline of machine/plant by using process descriptions. Also, users can choose between frequently used function diagrams or GRAFCET (Graphe Fonctionnel de Commande Etapes/Transitions) diagrams. PLC programmers receive timely information about necessary actuators and sensors and their desired operational interaction and timeline. Solution provides preplanning time for machine controls and also accelerates engineering processes.

Engineering Software facilitates enclosure layout.

EPLAN Software und Service GmbH & Co. KG    , -
Sep 29, 2011 Offering fully integrated solution, EPLAN Pro Panel 2.1 merges design, 3D layout, production, and mounting onto uniform database. Program supports dynamic collision control, automatic checking of respective installation conditions, and incorporation of devices used in electrical and fluid designs into mounting layout without manual synchronization. Modifications to housing, doors, or mounting plates can be transferred to appropriate production system via NC interface.

Engineering Data Portal includes data for 120,000+ electronic devices.

EPLAN Software und Service GmbH & Co. KG    , -
Aug 25, 2011 EPLAN Data Portal v2.0 enables users to quickly and easily select data relevant to their target market and focus on relevant components. Each device on portal is assigned a unique ID that allows its data to be updated even if local part number is changed, and device data can be displayed and filtered according to regional availability. Also, supplier-specific component configurators streamline availability and usage of this CAE component data.
