Equipment Analysis Software helps optimize productivity.

LVD Group    GULLEGEM, 8560
Nov 26, 2012 CADMAN®-OEE Overall Equipment Effectiveness software examines and reports on machine performance to optimize efficiency and productivity. Providing graphical charts for analysis, program uses presentation of shop floor information to optimize production process by increasing uptime and monitoring machine availability, function, and quality. It also includes module to measure effectiveness of sheet metalworking and laser, punching, and bending machinery.

Workshop Management Tool streamlines job workflow.

LVD Group    GULLEGEM, 8560
Jul 11, 2012 CADMAN®-Job organizes and schedules fabrication shop workload, classifying and grouping jobs in most efficient manner as to increase throughput, minimize setup time, and streamline work flow. In addition to creating or importing work orders from ERP system, workshop management tool generates jobs for bending or laser cutting. It also tracks progress of each work order, provides estimated and real production time information, and generates lists to launch any necessary re-work.

CNC Adjustable Vee Die is designed for press brakes.

LVD Group    GULLEGEM, 8560
Mar 07, 2012 Intended for PPEB and Easy-Form® precision press brakes, Vari-VEE V30-140 CNC adjustable Vee die offers benefits of variable and adjustable bottom Vee die to range of LVD Strippit press brake models from 320-1,000 tons and up to 315 in. long. Die provides automatic adjustment of V-width in increments of 0.39 in. and allows bending of angles up to 50° for max V-width. For optimal rolling and friction reducing properties, radius is a hardened insert, machined with STONE® compound curve.

Hydraulic Press Brakes are offered in 350-700 ton models.

LVD Group    GULLEGEM, 8560
Feb 06, 2012 PPEC Series is offered in 350-700 ton models with 2-axis (X, R) or 4-axis back gauge (X, R, Z1, Z2), 2 gauging fingers with 4 in. width, as well as choice of vertical load, North American. or Euro-style tooling. CADMAN Lite control offers 2D graphic programming with automatic collision detection, direct angle input or Quick Bend programming, and connection with CADMANB offline programming software.

CNC Turret Punch Press accommodates large workpieces.

LVD Group    GULLEGEM, 8560
Dec 22, 2011 Midrange 20 metric ton press, Strippit M-1525, handles workpieces up to 60 x 98.4 in. nominally or 60 x 157 in. with one sheet repositioning. Features include 47-station turret, three 3.5 in. auto-index stations, and four 2 in. stations. Able to accept diverse tooling, system also features hardened steel guide bushings, hardened shot pins, bi-directional turret rotation, and servo-driven hydraulic press drive. Axis speeds reach 400 and 850 hits/min on 1 and 0.04 in. centers, respectively.

CNC Turret Punch Press handles large and oversized workpieces.

LVD Group    GULLEGEM, 8560
Nov 09, 2011 Designed to handle workpieces up to 60 x 98.4 in., Strippit P-1525 delivers up to 270 hits/min on 1 in. centers and up to 600 hits/min in nibble mode. Machine processes material thicknesses up to 0.135 in. mild steel and up to 0.250 in. aluminum, providing ±.004 in. finished part accuracy and ±.002 in. finished part repeatability. In addition to servo-driven hydraulic ram, press features 21-station thick-style turret, three 2 in. auto-index stations, and PC-based Fanuc control.

Storage and Retrieval Tower operates with turret punch presses.

LVD Group    GULLEGEM, 8560
Jun 01, 2011 Designed for Strippit V, VT, M, and VX Series punch presses, Model CT-P facilitates unattended operation by providing loading, unloading, and storage of raw materials and finished parts. Available in 6-pallet and 10-pallet configurations, unit handles workpieces up to 98.4 x 48.2 in. and sheet weights up to 198 lb with max load/unload pallet storage capacity of 5,511 lb. Spreading magnet, air knife, and peeling cylinder prevent loading of more than 1 sheet at a time.

CNC Turret Punch Presses have energy efficient design.

LVD Group    GULLEGEM, 8560
May 04, 2011 Strippit M-Series presses feature 47-station turret that has three 3.5 in. auto-index stations and four 2 in. stations, all of which accept shaped punches, dies, and indexable multi-tools. Integrating servo-driven hydraulic press drive, systems support axis speeds up to 380 hits/min on 1 in. centers and up to 900 hits/min on 0.04 in. centers. Units manage workpieces up to 49.21 x 98.4 in., with thicknesses up to 0.250 in., and integrate Energy Reduction System to manage electrical power usage.

Touchscreen User Interface targets laser cutting systems.

LVD Group    GULLEGEM, 8560
Mar 29, 2011 Touch-L graphical interface uses icons and visual indicators to display and control functions such as: lens and nozzle selection, download of NC file to machine memory, file searching and editing, preview of part/nesting, and to provide real-time reproduction of cutting path. Interface lets operators change cutting quality, position and type of lead-in, and add or relocate micro joints. Supporting multiple extensions, including DXF/NC, it can also be used with USB memory and network drives.

CAD/CAM Software analyzes overall equipment effectiveness.

LVD Group    GULLEGEM, 8560
Sep 30, 2010 Operating on Windows® platform, CADMAN® streamlines fabricating process by offering one complete offline system for design, unfolding, punching, laser cutting, and bending of sheet metal parts. Overall Equipment Effectiveness (OEE) module provides analyses in graphical charts and uses presentation of shop floor information to help improve production process through monitoring machine availability, performance (theoretical cycle time versus real cycle), and quality.
