Electrically Conductive Adhesive from Henkel Compatible with Multiple Metals; Delivers Manufacturing Flexibility for Optical Technology Leader, LensVector


Leveraging research regarding contact resistance performance, Henkel Electronic Materials has developed an electrically conductive adhesive (ECA) that overcomes the drawbacks of older generation ECAs and extends the material's advantages to multiple applications. The adhesive system, HYSOL ECCOBOND CE 3103WLV, provides exceptional contact resistance stability on surfaces such as OSP copper and Sn alloys - metals which have previously been challenging for ECAs.

ECAs have been used for high-reliability applications such as automotive, medical and telecom products for some time, as they offer lower temperature processing, fine-pitch capability and improved thermal cycling resistance. With these applications, ECAs have most often been employed on devices with noble metallizations such as gold, silver, palladium and even ceramic substrates but have had limited success on common electronic metals such as copper and Sn alloys. Technical research conducted by Henkel, however, has revealed that electrochemical corrosion of these metals under elevated temperature and humidity is the root cause of the unstable contact resistance and, using this understanding as a foundation, Henkel developed HYSOL ECCOBOND CE 3103WLV to overcome these issues and deliver multi-metal compatibility.

The material has been incorporated into a variety of applications and, most recently, optical technology powerhouse, LensVector, has selected HYSOL ECCOBOND CE 3103WLV for use with its AutoFocus (LVAF) product. The LVAF is the world's smallest autofocus device, which uses a unique patented technology to transform a single liquid crystal cell into a variable focus lens which can then be integrated by camera module manufacturers to deliver autofocus capability.

LensVector's Vice-President of Engineering, Bahram Afshari, explains the demanding requirements of its product and why the company partnered with Henkel. "Not only do the contacts between the LVAF and the main module serve to make the electrical connections, but must also meet the challenging reliability requirements for camera phones, notebook computers and other handheld consumer electronic devices that incorporate these modules," says Afshari. "HYSOL ECCOBOND CE 3103WLV delivers the electrical conductivity and reliability performance in an easily dispensed, high-yield, low- temperature cure ECA. In fact, the cure temperature is well below most traditional ECAs, which gives us added process and module material selection flexibility."

The low temperature processing capability is a result of the unique formulation of HYSOL ECCOBOND CE 3103WLV, which utilizes new corrosion inhibitors and effectively extends its viability to applications requiring low-temperature processing. "This material is a highly effective alternative to solder for applications that must be processed at low temperature," says Tom Adcock, Henkel Global Product Manager for Assembly Adhesives. "Its ability to provide outstanding conductivity and reliability with multiple metallizations make it incredibly adaptable and its application effectiveness far-reaching."

The adaptability of the material was also a central component of LensVector's selection. "Identifying the right ECA is a critical step in LensVector's efforts to integrate this new autofocus technology into existing, fixed-focus camera modules," concludes Afshari. "HYSOL ECCOBOND CE 3103WLV enables the addition of autofocus capability without changing the module footprint."

To find out more about HYSOL ECCOBOND CE 3103WLV or any of Henkel's advanced ECAs, log onto www.henkel.com/electronics or call the company's customer and product support center at 1-888-943-6535.

About Henkel

Henkel operates worldwide with leading brands and technologies in three business areas: Laundry & Home Care, Cosmetics/Toiletries and Adhesive Technologies. Founded in 1876, Henkel holds globally leading market positions both in the consumer and industrial businesses with well-known brands such as Persil, Schwarzkopf and Loctite. Henkel employs about 48,000 people and reported sales of 15,092 million euros and adjusted operating profit of 1,862 million euros in fiscal 2010. Henkel's preferred shares are listed in the German stock index DAX and the company ranks among the Fortune Global 500.

About LensVector, Inc.

LensVector is leading a revolution in solid-state optics with solutions that replace moving parts of tiny cameras found in mobile phones, laptops and other consumer electronics with solid-state optical components. LensVector delivers the smallest autofocus products in the industry, making high-quality photography, m-commerce and video practical for everyone. LensVector solutions integrate easily with any camera module and are manufactured using proven, scalable processes from the LCD and semiconductor packaging industries. For more information, visit www.lensvector.com.
