Successful Completion of 3 Axis Diffractometer for Australian Synchrotron |
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
Rotary Precision Instruments UK Ltd
The Maltings Industrial Estate , Brassmill Lane
BA1 3JL, United Kingdom
Press release date: March 26, 2007
Rotary Precision Instrument (RPI) has successfully completed the supply of a High Accuracy 5 axis Diffractometer to the Australian Synchrotron in Melbourne. Although based on a similar product supplied to PSI (Paul Scherrer Institute) in Switzerland the product was tailored to meet MPV's load requirements and supplied with a through bore to accept their measurement equipment. MPV's request for a high accuracy Elevating Base Assembly was an engineering challenge for RPI, who previously have not supplied this axis.
In order to maintain the accuracy of the rotary axes the Base Assembly needed to have a high rigidity, a simple but innovative solution was provided which fully met the customers specification. The Base Assembly design, provides vertical adjustment of the equipment of ±40mm, with a 0.0005mm resolution (0.080mm = thickness of 1 Human Hair), to suit the beamline operating height.
The customers requirement for Roll and Yaw errors of ±4 arc seconds was also a challenge, however, during final calibration the measured results of 0.9 arc seconds of Yaw and 1.5 arc seconds of Roll were achieved.
For further information regarding Rotary Precision Instruments UK Ltd visit www.RPIuk.com or contact a member of our sales staff via email on sales@rpiuk.com or telephone on 01225 426206.
For information regarding Australian Synchrotron please visit synchrotron.vic.gov.au
