2 axis CNC turning Machine
We are interested to import following machine. If you are in a position to export the same machine as per given specification please inform us by return e-mail for further proceeding :-
2-Axis CNC Turning Machine
Name of the Machine : 2-Axis CNC Turning Machine with all standard accessories and attachment as per specification below :
Specification :
(a) Capacity :
1. Swing over bed : 350 370 mm
2. Swing over cross slide : 200 210 mm
3. Swing in gap : 580 600 mm
4. Gap width from faceplate : 155 165 mm
5. Distance between centers : 750 770 mm
(b) Spindle
1. Spindle Centre height : 1030 1040 mm
2. Spindle Nose : A2-5
3. Spindle bore : 50 60 mm
4. Maximum Spindle speed : 5000 rpm
5. Spindle speed ranges : 270 5000 rpm
6. Maximum spindle motor power : 7 7.5 kw
(c) Tailstock
1. Tailstock quill diameter : 70 80 mm
2. Tailstock quill taper : No. 4 MT
3. Tailstock quill travel : 115 125 mm
By Sheikh Moniruzzaman on Sep 3, 2009 02:28
