Formaplex Continues 5-Axis Expansion |
DMG America, Inc.
265 Spring Lake Dr.
Itasca, IL, 60143
USA
Press release date: January 12, 2012
Havant-based rapid manufacturing company, Formaplex, a leading supplier to the motorsport, automotive and aerospace industries, has ordered two DMU100U monoBLOCK 5-axis machining centres from DMG (UK). They will be installed in May 2012 to assist the company in meeting short-lead-time deliveries to demanding customers.
Moulds, dies and master patterns, mainly in aluminium, for plastic and composite component production are manufactured around the clock by Formaplex, in addition to prototype parts. Formaplex's Metallic Division installed its first two large 5-axis machines in 2009 and 2010, capable of unmanned processing of parts up to 3 metres in X, but was finding that bottlenecks were forming in the production of smaller, complex components.
The DMU machines have a 1,250 x 710 x 710 mm working volume, a full NC rotary axis within the main 1,500 mm x 800 mm table surface, and a high powered B-axis milling head with a swivel range of -120 /+30 degrees. It was partly the versatility of this configuration, as opposed to the more common trunnion design, that prompted Formaplex to opt for DMG machines.
Ben Yule, Operations Manager at Formaplex, commented, "With the trend towards ever greater component complexity, our recent entry into 5-axis manufacturing revolutionised our operations and is allowing us to continue to beat customer deadlines.
"Investigations into potential suppliers of similar machines for producing small to medium sized parts led us to conclude that DMG has the track record and industry reputation to be considered market leader.
"Trunnion-type five-sided machining is virtually non-existent here, whereas the universal head design of the DMU lends itself well to our type of work, such as mould / die profiling and 3- plus 2-axis drilling of compound holes.
"In fact the configuration is more like a 3-axis vertical machining centre with 5-axis capability and all-round accessibility is good. We also like the Heidenhain CNC option, as all of the machines on our shop floor are similarly equipped."
DMG (UK) Ltd, Unitool House, 151 Camford Way, Luton, Bedfordshire, LU3 3AN.
Tel: 01582 570661. Fax: 01582 593700.
E-mail: dianne.taylor@gildemeister.com
Web site: www.gildemeister.com
Contact: Richard Watkins, Managing Director.
