FEI Hits Production Milestone for Helios NanoLab DualBeam
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
5350 NE Dawson Creek Dr.
Hillsboro, OR, 97124
Press release date: April 21, 2011
Ships 250th system as a result of expanded market adoption across a wide range of industries
Hillsboro, Ore.- FEI (NASDAQ: FEIC), a leading instrumentation company that provides microscopy systems for research and industry, today announces that it has shipped the 250th Helios NanoLab(TM) DualBeam(TM) system. Since its introduction in 2006, the award-winning Helios NanoLab has experienced widespread market acceptance.
"The Helios NanoLab DualBeam provides the SEM and FIB performance needed to solve some of the critical roadblocks to advancing technology and sciences across many disciplines," said John Williams, vice president of marketing, FEI. "It has been adopted by leading semiconductor manufacturers for their most advanced research and development needs; it is being used by major academic and industrial research laboratories for advanced material characterization and modification down to the single nanometer scale; and it has even expanded into the life sciences and oil & gas industries due to its ability to provide three-dimensional imaging at the nanoscale."
FEI was the first to commercialize the DualBeam almost 20 years ago, and the latest Helios NanoLab x50 DualBeam Series is the most powerful and versatile DualBeam system available on the market today. It integrates FEI's high-resolution scanning electron microscope (XHR SEM) with a new, high-performance focused ion beam (FIB), to deliver an unprecedented level of imaging and milling capability. Customers across a variety of industries have had great success with the DualBeam's unique set of capabilities in a variety of applications, including:
o academic and industrial research centers use the Helios NanoLab system for advanced 2D and 3D materials characterization, leading-edge sample preparation and nanoprototyping of nanoscale prototypes of electronic, optical, and mechanical devices;
o advanced semiconductor fabs are using the system for fast and precise preparation of ultrathin samples for transmission electron microscope (TEM) analysis;
o life scientists can view features of interest in tissue and cells three dimensionally, using the Helios system's "slice and view" (3D reconstruction) capability;
o and the oil & gas industry is using the Helios to optimize and extract natural gas that is hidden in many unconventional reservoirs, such as tight sands, gas shales and coalbed methane.
"The ability to deliver high resolution imaging on almost any material, and to manipulate those materials with minimal damage, has allowed the Helios NanoLab DualBeam to play an important role in a variety of disciplines," Williams adds.
FEI (Nasdaq: FEIC) is a leading diversified scientific instruments company. It is a premier provider of electron- and ion-beam microscopes and tools for nanoscale applications across many industries: industrial and academic materials research, life sciences, semiconductors, data storage, natural resources and more. With more than 60 years of technological innovation and leadership, FEI has set the performance standard in transmission electron microscopes (TEM), scanning electron microscopes (SEM) and DualBeams(TM), which combine a SEM with a focused ion beam (FIB). FEI's imaging systems provide 3D characterization, analysis and modification/prototyping with resolutions down to the sub-Ångström (one-tenth of a nanometer) level. FEI's NanoPorts in North America, Europe and Asia provide centers of technical excellence where its world-class community of customers and specialists collaborate. FEI has approximately 1800 employees and sales and service operations in more than 50 countries around the world. More information can be found at: www.fei.com.
