BEI Kimco Magnetics Voice Coil Actuator Solves Demanding Application Requirements for High Force Density Capabilities
|
|
Click Here to Enlarge Picture
|
|
(Archive News Story - Products mentioned in this Archive News Story may or may not be available from the manufacturer.)
BEI Kimco Magnetics
1499 Poinsettia Ave., Suite 160
Vista, CA, 92081
USA
Press release date: November 2, 2010
VISTA, Calif, BEI Kimco Magnetics, a company of Custom Sensors & Technologies (CST), Inc., recently met the challenging VCA requirements for a cutting tool utilized in an Ophthalmic Lens Grinding application. This application required an actuator with high Force/Acceleration capabilities and high speed position control to meet the desired cutting tool performance.
Key to the product's design specification was a high force density voice coil actuator that would deliver 1378 N of peak force with a maximum acceleration of 1500 m/s^2. Another important requirement was reliable operational performance at ambient temperature of 40 degrees C.
To meet these demanding requirements, BEI Kimco provided Voice Coil Actuator Model LA43-67-000A. This un-housed actuator features an exceptional actuator constant (KA) of 28.02 N/watt^0.5, achieved by the patented optimal design configuration and the use of strong, high energy product rare earth magnets. Compact in size, the device measures only 108 mm in diameter and 170 mm in length (at mid-stroke). Utilization of the LA43-67-000A Voice Coil Actuator also allowed automatic calibration with accurate and fast alignment of the turning system without operator assistance, eliminating the need for manual adjustment and providing a significant time-savings advantage.
"High acceleration and high system precision are the two main advantages made possible by using voice coil actuators", says Miguel Hermosillo, BEI Kimco's Applications Engineer for VCAs. "We provided a high Force/low moving Mass Actuator that allowed our customer to design a fast tool capable of delivering one of the highest productivity freeform lens turning process in the industry".
BEI Kimco Voice Coil Actuators have been used successfully in countless applications from high-end Industrial to Military and Aerospace to Medical applications. The ability to provide high performance solutions tailored to the specific needs of the customer has allowed BEI Kimco to fulfill many challenging requirements. For detailed specifications on the LA43-67-00A, go to http://www.beikimco.com/pdf/LA43-67-000A.pdf or contact BEI Kimco Magnetics, 2470 Coral Street, Bldg. D, Vista, CA 92081-8430, USA, Tel: (760) 597-7042; Toll-free: (800) 572-7560; Fax: (760) 597-6320; email: sales@beikimco.com; www.beikimco.com
About BEI Kimco Magnetics:
BEI Kimco Magnetics is an operation of Custom Sensors & Technologies (CST). BEI Kimco Magnetics was founded in 1974 and specializes in rotary and linear motion control products. The company's precision motion control products include high-speed performance Brushless DC motors, Cylindrical and Flat Voice Coil Actuators, and Linear Motors. These products are used across a wide range of applications including medical and scientific, factory and office automation, optics, semiconductor/electronics, military, aviation, space systems, and security. Kimco merges leading-edge capabilities and cost-effective manufacturing know-how with highly customized applications expertise. www.beikimco.com
About Custom Sensors & Technologies:
Custom Sensors & Technologies (CST) is a specialist in sensing, control and motion products.
Through its brands, BEI Kimco, BEI Sensors, BEI PSSC, Crouzet, Crydom, Kavlico, Newall and Systron Donner, CST offers customizable, reliable and efficient components for mission-critical systems in Industrial, Aerospace & Defense, and Transportation markets. Focused on premium value offers and committed to excellence, CST, with more than 4,000 employees worldwide and sales of $530M US in 2009, is the dependable and adaptable partner for the most demanding customers. www.cstsensors.com
|
|
|
|
|
|
|
