Automation Products Group, Inc. Release date: June 18, 2008
LOGAN, UT - LPU-2428 Loop Powered Ultrasonic Level Sensors from Automation Products Group, Inc. (APG) are now cCSAus certified for use in Class I, Div. 1, Groups C and D, and Class I, Zone 0, Group IIB hazardous locations. Class I, Div. 1, Group C, and Class I, Zone 0, Group IIB atmospheres contain ethyl-ether vapors, ethylene, or cyclopropane. Class I, Div. 1, Group D atmospheres contain gasoline, hexane, naptha, benzene, butane, propane, alcohol, acetone, benzol, lacquer solvent vapors or natural gas.
LPU-2428 sensors feature microprocessor control to internally perform volume, flow, and totalization calculations. They provide a 1 to 25 ft. (0.3 to 7.62 m) detection range on liquids and a 1 to 10 ft. (0.3 to 3.0 m) detection range on solids. These sensors are well suited for environmental monitoring, water and wastewater control, and liquid tank measurement applications. They are also suited for other industrial and process control applications where liquid volume or flow needs to be monitored and controlled.
For determining flow rates, formulas for a variety of flumes and weirs are built into the sensors. These include Parshall flumes, cut-throat flumes, California-pipe weirs, rectangular weirs, and v-notch weirs. Equation-based calculations are also possible. LPU-2428 sensors provide an output directly proportional to the flow rate, and users can select flow rate units of per second, per minute, per hour, or per day. Standard volume units include cubic feet, millions of cubic feet, gallons, cubic meters, or liters. For volume measurement, the sensors have built-in formulas for most industry-standard tank shapes.
LPU-2428 sensors feature a rugged PVDF (Kynar) transducer housing and PC/PET chemical resistant sensor housing, and are easy to install using industry standard 2-inch NPT fittings. These sensors can operate in temperatures from -40 to 140ºF (-40 to 60ºC) and deliver 0.1 in. (2.5 mm) resolution with accuracy of ± 0.25% of the detected range, and response time of 0.6 to 3 seconds depending on the output range.
The LPU-2428 features internal temperature compensation to automatically account for changes in ambient temperature, as well as filtering options to account for other variables such as waves on a liquid or tank irregularities. They are unaffected by the color/translucency, dielectric constant, specific gravity or viscosity of the target. Internal parameters are setup using a remote keypad & display unit.
About Automation Products Group
Automation Products Group, Inc. (APG) supplies tailored sensing solutions for measurement applications to process control industries. They serve the water and wastewater, oil and gas, telemetry integration, car wash OEM, as well as cooking and lubricant oil recycling markets with a complete family of presence, level, flow and pressure sensing technologies. APG has roots in the sensor business spanning more than 35 years.
Automation Products Group, Inc.,
toll-free: 1-888-525-7300;
(435) 753-7300;
fax: (435) 753-7490;
E-mail: sales@apgsensors.com,
Web site: www.apgsensors.com.
Chris Nelson
Longren & Parks
416 - 7th Street South
Hopkins, MN 55343
612-237-4443
Chris@longrenparks.com
Company Information:
Name: Automation Products Group, Inc.
Address: 1025 W. 1700 N.
City: Logan
State: UT
ZIP: 84321
Country: USA
Phone: 888-525-7300
FAX: 435-753-7490
http://www.apgsensors.com/
|
