Oscilloscope Software decodes protocol packets.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Mar 27, 2013 Designed to run on Infiniium 9000A and 9000 H-Series oscilloscopes as well as 90000A, 90000 X-, and 90000 Q-Series, N8824A Software decodes protocol packets for MIPI RFFE v1.10 specification. R&D design and validation teams can use software to address startup debugging and to examine traffic between RF front-end devices. Using decoder with oscilloscope also allows engineers to meet accurate timing requirements associated with RFFE packets.

Multiport Optical Power Meters are optimized for sensitivity.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Mar 21, 2013 Programmable with SPCI commands, both 2-channel N7747A and 4-channel N7748A enable engineers to make parallel multiport measurements and monitor weak signals and small signal changes. Instruments can detect power levels down to -110 dBm and log data at intervals down to 25 µsec with up to 1 million points per channel. Equally large data buffer supports simultaneous measurement and data transfer. USB 2.0, LAN, and GPIB interfaces are included as standard.

Multi-wavelength Meter has 2 year recalibration period.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Mar 21, 2013 With ±0.2 ppm absolute wavelength accuracy and ±0.15 ppm differential accuracy, Agilent 86122C is suited for optical communication testing. Wavelength range of 1,270–1,650 nm covers all fiber-to-the-home, metro, and long-haul transmission systems, while ability to simultaneously measure spectra of up to 1,000 laser lines exceeds requirements for fully populated DWDM systems. Measurement applications for optical SNR, wavelength, and power drift are built in.

Atomic Force Microscope supports multiple stages for versatility.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Mar 18, 2013 Along with fully addressable and programmable 200 x 200 mm stage and stage adapter for imaging small samples, 5600LS supports 300 x 300 mm stage for handling larger semiconductor wafer samples and multisample 2 in. wafer stage suited for research involving optoelectronics and LEDs. Motorized stage accommodates single sample up to 200 mm dia x 30 mm tall or up to 9 small samples with 200 mm vacuum chuck; probes are positioned to image and map specimens with 0.5 µm precision.

Compliance Testing Software addresses automotive serial buses.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Mar 12, 2013 Covering all equipment needed for physical-layer testing, including oscilloscopes, spectrum analyzers, and pulse/function generators, Agilent N6466A MOST (Media-Oriented Systems Transport) application provides automated test script that allows engineers to test MOST50 and MOST150 signals, while Agilent N6467A BroadR-Reach provides rapid testing of automotive BroadR-Reach network devices. Both solutions can be automated to run over extended periods.

Wireless Communications Test Set includes multiport adapter.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Mar 07, 2013 Capable of testing multiple devices simultaneously, E6607C EXT maximizes test throughput. One-box tester includes vector signal analyzer, sequence analyzer, 8 bi-directional I/O ports for multiformat cellular testing, and 4 output ports for GNSS testing. Optimized for fast-sequenced nonsignaling test methods required by wireless-modem chipsets, sequence analyzer works in synchronization with chipset to eliminate signaling overhead and enable multiple measurements from single acquisition.

Host Adapter accelerates RFIC protocol testing.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Mar 04, 2013 Providing serial stimulus needed to evaluate and characterize circuits based on DigRF v4 specification, M9252A DigRF Host Adapter offers protocol testing solution for MIPI™ Alliance Gear2 DigRf v4 RFICs. Single module combines stimulus and Rx side capture to generate configurable control and data traffic and allow developers to observe response from DUT. Engineers can work in domain of their choice (digital or radio frequency) to characterize device's digital and wireless behavior.

Boundary Scan Analyzer aids board design and validation.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 28, 2013 Providing 4 test access ports and 22.5 MHz TestClock, Model x1149 can be used throughout product development cycle, from design and validation to high-volume production. Benchtop system offers actionable pin-level failure reporting, STAPL player for CPLD/FPGA tests, and Scan Path Linker which enables multiple chains to be linked into single chain. With Cover-Extend Technology, test coverage can go beyond just IEEE 1149.1 devices to also include connectors, sockets, and non IEEE 1149.1 devices.

UFS Procotol Decoding Software runs on oscilloscopes.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 28, 2013 Running on Infiniium 90000A, 90000 X-Series, and 90000 Q-Series oscilloscopes, N8818A Software decodes protocol packets for JEDEC's Universal Flash Storage v1.1 specification, enabling engineers to validate and debug UFS interfaces. Software supports MIPI M-PHY speeds of up to 5.8 Gbps. It provides symbol, packet, frame, and payload detail of protocols; high-speed/low-speed PWM transmission modes; cyclical redundancy checks on packets; and search capability for frames, sequences, and errors.

Compliace Testing Application provides EEE standards assessment.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 19, 2013 Agilent N5392B provides automated script that lets engineers test Energy-Efficient Ethernet (EEE) signals used in networking applications. Specifically, this solution for transmitter tests includes 10/100/1000BASE-T EEE test standards as described in IEEE 802.3az-2010 specification. Application can be automated to run over extended periods and also allows engineers to add incremental user-defined tests. In addition to EEE, software includes support for other Ethernet standards.

EDA Software accelerates MIMO radar and wireless/4G design.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 19, 2013 Combining real-world modeling and standards-based validation, SystemVue 2013.01 helps make critical decisions about RF and DSP architecture. W1905 radar model library offers signal-processing support for array-based radar technologies such as MIMO, phased-array, and synthetic-aperture radars. Software enables system-level modeling of multi-standard radio performance under 3GPP Release-9 TS 37, and digital predistortion for power amplifiers in 4G/LTE and wireless LAN 802.11ac applications.

Network Analyzers offer noise-figure measurement to 50 GHz.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 18, 2013 Built into PNA-X Network Analyzers, source-corrected noise-figure measurement technique provides single-connection, multiple-measurement capability for users developing and testing low-noise transistors, amplifiers, frequency converters, and transmit/receive modules. Analyzers combine S-parameter vector-error correction and impedance tuner to remove effects of imperfect system source match. Solution also corrects for interaction between output match of DUT and noise figure of internal receiver.

UniPro, LLI Protocol Decoders enhance ocilloscope capabilities.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 18, 2013 Run on Infiniium 90000 Series oscilloscopes, N8808A UniPro and N8809A LLI protocol decoders accelerate and facilitate validation and debugging of design and validation engineers' embedded MIPI™ Unified Protocol (UniPro) and Low Latency Interface (LLI) interfaces. Software specifically enables protocol decoding for MIPI Alliance UniPro v1.41 and LLI v1.0 specifications and supports MIPI M-PHY Gear-3 speeds of up to 5.8 Gbps, which these protocols use for their electrical layers.

Signal Analyzers support real-time spectrum analysis.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 15, 2013 Real-time spectrum analysis (RTSA) for PXA X-Series signal analyzers helps system developers and signal analysts see, capture, and comprehend elusive signals. When configured for real-time spectrum analysis, PXA can detect intermittent signals with durations as short as 3.57 µsec. Solution provides 75 dB spurious-free dynamic range across analysis bandwidths up to 160 MHz, sensitivity of -157 dBm at 10 GHz (no preamp), and ability to vary resolution bandwidth within measurement span.

Turbomolecular Vacuum Pump uses floating-suspension technology.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 14, 2013 Running at 60,000 rpm, TwisTorr 304 FS pumps up to 250 Lps for N2; drag stages ensure high pumping speed and compression ratios for hydrogen and helium. Floating-suspension technology minimizes vibration and acoustical noise while providing optimal working conditions for bearings as well as stability for demanding applications and instruments. Compact rotor design reduces power consumption, and bearing and dry lubricated suspension system permits installation in any orientation.

Basic Spectrum Analyzer covers 9 kHz to 7 GHz range.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 13, 2013 Suited for budget-constrained applications, Model N9322C features typical -152 dBm DANL for viewing low-level signals clearly, and ±0.1 ppm annual aging rate, which minimizes frequency drift. Seven user-definable soft keys provide quick access to 7 most frequently used measurement setups, while optional 7 GHz tracking generator with built-in VSWR bridge supports transmission and reflection measurements. With demodulation mode, users gain more insight into AM, FM, ASK, and FSK signal analysis.

Atomic Force Microscope suits nanoscale life science research.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 07, 2013 Along with top-view video optics package that lets researchers see opaque samples while scanning, 6000ILM is available with incubator perfusion cell sample plate that facilitates dynamic studies in liquids and gases. Plate provides continuous perfusion, offers variable flow-through, and maintains liquid level. Single-pass electrical characterization capabilities and force-volume spectroscopy capabilities, along with PicoView software plug-ins and scripting, expand application versatility.

Oscilloscopes support USB 2.0 signal quality test option.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 04, 2013 Available for InfiniiVision 4000 X-Series oscilloscopes, DSOX4USBSQ USB 2.0 signal-quality test option lets engineers verify analog quality of signals generated by USB hubs, hosts, and devices based on USB-IF compliance standards. Option supports low-speed, full-speed, and hi-speed USB applications. It generates HTML pass/fail reports for eye-diagram mask testing, jitter analysis, end-of-packet bit width, signaling rate, edge monotonicity, and rise/fall times.

Oscilloscopes are available in MSO, DSA, and DSO versions.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Feb 01, 2013 Infiniium 90000 X-Series includes 6 mixed-signal oscilloscope (MSO) models with DDR triggering mode as well as 13 GHz DSO and DSA models. Integrated digital channels of MSO models can function at 20 or 10 GSPS in 8- or 16-channel configurations, respectively. Offering 70 MHz to 33 GHz of analog bandwidth, MSOs have up to 400 million points of data capture behind each digital channel. DSO, DSA, and MSO models give engineers access to low-noise and low-jitter measurement.

Benchtop Digital Multimeter performs 11 measurement functions.

Agilent Technologies, Inc.    Santa Clara, CA 95051
Jan 25, 2013 Capable of measuring up to 190 readings/sec with 0.015% DCV accuracy, 5 ½-digit Model 34450A is intended for electronic test and measurement applications for industrial and educational use. Multiple connectivity options, including USB 2.0, RS-232, and GPIB, give users flexibility when transferring data to PC for analysis. With up to 50,000 readings of onboard memory, users can log up to 14 hr of data at 1 sample/sec. OLED display enables users to set up measurement functions using 1-page menu.
