Aluminum-Housed Resistors offer power ratings from 50 to 500 W.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Mar 15, 2013 Available in horizontal or vertical arrangements, IP20 or IP65 rated Draloric VACR series comes in 160 x 40 x 20 mm to 337 x 60 x 30 mm enclosures depending on power rating. Standard tolerance is ±10%, with max permissible operating voltage of UL 600 V and/or UL 1000 V, depending on model. With short-term loads, resistors are characterized by up to an eleven-fold overload (on-time 6% with 120 sec cycle duration). E24 series resistance values are standard, and others are available.

Low Input Current Optocouplers provide phototransistor output.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Mar 12, 2013 Housed in SSOP-4 mini-flat package, Series VOS618A and VOS617A feature DC input currents of 1 mA and 5 mA, respectively. Units have GaAs infrared emitting diode, which is optically coupled to silicon planar phototransistor detector. SSOP-4 package provides 3,750 Vrms isolation voltage rating, half lead pitch of 1.27 mm, and creepage/clearance distance of ≥5 mm. Offering CRT ranges from 40–600%, devices protect users from electrical shocks and microprocessors within systems from voltage spikes.

Axial Cemented Wirewound Resistor has 2 kV surge capability.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Mar 05, 2013 Featuring fusing time of less than 30 sec for 45 W overload, AC03..CS offers cement coating for immediate interruption without flame and explosion when mains voltage (220 Vrms) is applied and acts as in-rush current-limiting resistor during normal operation. Lacquer coating matches thermal and electrical insulating properties of silicone cement. Along with 2 kV (30 pulses/15 min) surge capability, features include 10–100 Ω resistance, ±5% resistance tolerance, and ±200 ppm/K TCR.

Ignitor Chip Resistor features firing energy down to 1.5 mJ.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Feb 25, 2013 Available in wraparound or flip chip versions as well as integrated on PCB substrate, Sfernice MEPIC Massive Electro-Pyrotechnic Ignitor Chip Resistor offers Joule effect or flash ignition for fast firing times down to 250 µs. Unit converts electrical energy into heat energy in precise electro-thermal profile for purpose of initiating series of pyrotechnic events in controlled energetic reaction. With ohmic range of 2 Ω ±10%, device is suited for deployment of airbags and other safety devices.

Surface-Mount Aluminum Capacitors operate up to 150°C.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Feb 15, 2013 Available in 6 case sizes ranging from 12.5 x 12.5 x 13 mm to 18 x 18 x 21 mm, 160 CLA Series is designed to meet IPC/JEDEC J-STD-020 soldering guidelines for severe reflow conditions. Polarized aluminum electrolytic capacitors feature max impedance of 0.035 Ω at 100 kHz, ripple current to 1.35 A, and useful life of 2,000 hr at +150°C. Designed with non-solid, self-healing electrolyte, AEC-Q200-qualified units offer capacitance from 100–3300 µF over 16–50 V range.

Thin Film Chip Resistors offer ohmic values down to 1 ohm.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Feb 14, 2013 Supplied in 0406 package, AEC-Q200-qualified MCW 0406 AT Precision series offer precision tolerance of ±0.1% and precision TCR of ±25 ppm/K. Wide terminal thin film chip resistors perform up to +155°C and feature power dissipation of 250 mW at ambient temperature of 70°C. On 4-layer FR4 PCB, devices handle up to 2,500 cycles of rapid temperature change over -40 to +125°C span. They are also qualified per accelerated tests, including operation at +85°C at 85% RH for 1,000 hr.

Thin Film Chip Resistors feature resistance down to 1 Ohm.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Feb 11, 2013 Supplied in 0406 package, MCW 0406 AT Precision Series provides precision tolerance of ±0.1% and precision TCR of ±25 ppm/K. AEC-Q200-qualified units offer high-temperature performance to +155°C and power dissipation of 250 mW at ambient temperature of 70°C. On 4-layer FR4 printed circuit board, devices handle up to 2,500 cycles of rapid temperature change over span of -40 to +125°C. Typical applications include power measurement in industrial and automotive electronics.

Wirewound Resistors offer 12 kV surge withstanding capability.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Feb 04, 2013 Comprised of axial cemented wirewound resistors, Z300-C series limits in-rush currents during high voltage surges. Voltage surge withstand capabilities reach up to 12 kV per IEC 61000-4-5 (1.2 µsec/50 µsec), and power ratings range from 1–6 W at 40°C ambient and 0.9–5.4 W at 70°C. Along with resistance from 0.15 Ω to 10 kΩ, these RoHS-compliant devices feature resistance tolerances of ±5% and ±10%, TCR of ±200 ppm/K (±400 ppm/K below 1 Ω), non-flammable cement coatings, and ceramic cores.

Wirewound Resistors withstand voltage surges up to 12 kV.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Jan 30, 2013 Providing power ratings from 1–6 W at ambient temperature of 40°C and 0.9–5.4 W at 70°C, Z300-C Series offers resistance from 0.15 Ω to 10 kΩ, resistance tolerances of ±5% and ±10%, and TCR of ±200 ppm/K. Devices feature non-flammable cement coatings and ceramic cores for safety in overload conditions. Designed to limit in-rush currents during surges, RoHS-compliant resistors are optimized for power supplies in electronic meters, industrial and home appliances, and electronic ballasts.

Solid Tantalum Chip Capacitors have low-profile design.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Jan 22, 2013 Supplied in case sizes down to 0805 with profiles from 0.8–1.0 mm, molded MICROTAN® solid tantalum chip capacitors of TL8 series offer capacitance-voltage ratings from 3.3 µF-35 V to 220 µF-4 V and standard capacitance tolerances of ±10% and ±20%. RoHS-compliant products, featuring lead (Pb)-free, L-shaped facedown terminations, operate from -55 to +85°C (+125°C with voltage derating), and help save board space in handheld, battery-operated consumer electronics.

Power MOSFETs offer on-resistance down to 20 mOhm at 4.5 V.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Jan 16, 2013 Housed in 1.6 x 1.6 x 0.6 mm CSP MICRO FOOT® package, 8 V n-channel Si8424CDB and -20 V p-channel Si8425DB offer maximum on-resistance of 20 mΩ and 23 mΩ, respectively, at 4.5 V gate drive. Smaller 8 V n-channel Si8466EDB, measuring 1 x 1 x 0.55 mm, features max on-resistance of 43 mΩ at 4.5 V and provides 3,000 V typical ESD protection. RoHS-compliant and halogen-free, TrenchFET® power MOSFETs are suited for battery or load switching in power management applications for portable electronics.

Rectifiers and Soft Recovery Diodes reduce switching losses.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Jan 11, 2013 With reverse recovery times down to 14 ns, FRED Pt® and HEXFRED® Hyperfast and Ultrafast rectifiers and soft recovery diodes suit high-frequency full and mild hybrid vehicle systems and HID lighting. Devices in DPAK offer 200 and 600 V reverse voltages and include 6 A and 8 A FRED Pt rectifiers as well as 4 A HEXFRED diode. Components in TO-220, D²PAK, TO-262, TO-247, and modified TO-247 packages offer 600 and 1,200 V reverse voltages and include 15–60 A FRED Pt devices and HEXFRED diodes.

N-Channel Power MOSFET (100 V) offer optimized on-resistance.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Jan 08, 2013 Respectively, SiB456DK and SiA416DJ TrenchFET® power MOSFETs come in thermally enhanced PowerPAK® SC-75 1.6 x 1.6 mm and PowerPAK SC-70 2 x 2 mm packages and offer on-resistance of less than 200 and 100 mΩ. Respective on-resistance times gate charge values for SiA416DJ are 540 mΩ-nC at 10 V and 455 mΩ-nC at 4.5 V, while values for SiB456DK are 611 mΩ-nC at 10 V and 558 mΩ-nC at 4.5 V. MOSFETs are optimized for boost converters, low-power DC/AC inverters, and primary side switching.

SMT Biodirectional TVS features surge capability to 3 kW.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Dec 31, 2012 With surge capability to 3 kW at 10/1,000 µsec, SMC3K series protects sensitive electronic equipment in automotive and telecom applications against voltage transients induced by system inductive load switching and lightning. Low-stress, symmetric lead frame designs provide reliability required for automotive applications, and each AEC-Q101-qualified TRANSZORB® TVS comes in SMC DO-214AB package. Stand-off voltages range from 22–78 V, and peak pulse surge current varies from  23.8–84.5 A.

Surface Mount Resistor features 2 W power rating.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Dec 24, 2012 Available in 2010 case size, Power Metal Strip® WSLP2010 features resistance values from 0.001–0.01 Ω with tolerances of 0.5 and 1.0%. Advanced all-welded construction incorporates solid metal nickel-chrome or manganese-copper alloy-resistive element with TCR of less than 20 PPM/°C, resulting in operating temperature of -65 to +170°C. Providing 0.5–5 nH inductance and thermal EMF of less than 3 µV/°C, RoHS-compliant device is suited for all types of current sensing and pulse applications.

SMT Bidirectional TVS features 3 kW surge capability.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Dec 20, 2012 Supplied in SMC DO-214AB package for automotive and telecom applications, TRANSZORB® bidirectional TVS protects sensitive electronic equipment against voltage transients induced by system inductive load switching and lightning. There are 19 AEC-Q101-qualified devices with surge capability to 3 kW at 10/1,000 µsec, stand-off voltages from 22–78 V, peak pulse surge current from 23.8–84.5 A, max clamping voltage from 35.5–126 V, and operating range of -55 to +150°C.

High-Current Automotive Inductor operates up to +155°C.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Dec 18, 2012 Housed in RoHS-compliant, shielded composite package, Model IHLP-8787MZ-5A provides current ratings from 9.7–180 A, max DCR from 0.17–28.30 mΩ, and inductance values from 0.22–100 µH. Device handles high transient current spikes without hard saturation. Featuring 8787 case size and frequency range up to 1 MHz, inductor serves as space- and power-saving solution for engine and transmission control units, diesel injection drivers, navigation systems, and power seats/mirrors.

Precision Matched-Pair Resistor Networks are AEC-Q200 qualified.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Dec 17, 2012 Supplied in molded SMT SOT-23 package, MPMA series is constructed using moisture-resistant thin film tantalum nitride resistor film with enhanced passivation on high-purity alumina substrate. Devices are resistant to moisture at +85°C, 85% RH, and 10% rated power per MIL-STD-202. Additional properties of these products include TCR tracking of ±2 ppm/°C, tight ratio tolerance to ±0.05%, and resistance from 250 Ω to 50 kΩ with divider ratios from 1:1 to 50:1.

MELF Resistor Sample Kits promote design experimentation.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Dec 17, 2012 To facilitate prototyping and accelerate time to market for range of electronic systems, 2 laboratory sample kits respectively offer ~100 resistance values for precision MELF resistors in MMA 0204 and MMB 0207 packages. Each supplies 20 thin film resistors for every fourth value of E-96 series with 0.1% tolerance and temperature coefficient of ±25 ppm/K. There are 2,180 AEC-Q200-qualified resistors supplied in each kit, fostering freedom of experimentation in design processes.

SMT PAR® TVSs serve automotive and telecom applications.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Dec 11, 2012 Supplied in DO-214AB package, 5KASMC series has surge capability to 5 kW at 10/1000 μsec that increases design flexibility and compatibility. Operating junction temperature range of -65 to +185°C and low-stress, symmetric lead frame designs lend to reliability for automotive applications. These AEC-Q101-qualified products protect sensitive electronic equipment against voltage transients induced by system inductive load switching and lightning. Stand-off voltages range from 10–43 V.
